KOBE Brand Range Hood Model No.
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS Important Safety Instructions.................................................................................................1 Components of Package.......................................................................................................3 Installation.............................................................................................................................4 Operation Instructions ................................................
IMPORTANT SAFETY INSTRUCTIONS - PLEASE READ THIS SECTION CAREFULLY BEFORE INSTALLATION - WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL INJURY, OBSERVE THE FOLLOWING: 1) Installation and electrical wiring must be done by qualified professionals and in accordance with all applicable codes and standards, including fire-rated construction. 2) When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other hidden utilities.
What to Do In The Event Of a Range Top Grease Fire SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911. NEVER PICK UP A BURNING PAN – You May Get Burned. DO NOT USE WATER, including wet dishcloths or towels – a violent steam blast will result.
COMPONENTS OF PACKAGE (M u s t k e e p a ll m a te ria l fo r re tu rn s o r re fu n d s ) RANGE HOOD BOX ORIGINAL KIT – Model No.
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation Calculate the length of the installation, before installing the hood. (All calculation is measure in inches.
S A F E T Y W A R N IN G HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF IT IS NECESSARY TO REMOVE ANY PARTS FOR INSTALLING, CLEANING OR SERVICING. NOTE: BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER, DAMAGE TO THE HOOD MAY OCCUR. Installation Contents Under the Cabinet .................................................................................................................6 Stand Alone ................................................................................................
UNDER THE CABINET INSTALLATION Figure 1 Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. Refer to Figure 1. A straight, short venting run will allow the hood to perform more efficiently. Try to avoid as many transitions, elbows, and long run as possible. This may reduce the performance of the hood.
Figure 5 Ductwork Installation 5. 6. Use aluminum or steel pipe to connect the 6” round plastic exhaust on the hood to the ductwork above. Use duct tape to make all joints secure and air tight. Refer to Figure 4. To convert ductwork to 7” round, attached 7” round adapter (provided) to the 6” round plastic exhaust. Wiring to Power Supply S A F E T Y W A R N IN G Figure 6 RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST BE PROPERLY GROUNDED.
STAND ALONE INSTALLATION ***This installation only applied with the purchase of a duct cover (Model No. RA1020DC). Figure 8 Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. (Figure 1) A straight, short venting run will allow the hood to perform more efficiently. Try to avoid as many transitions, elbows, and long run as possible.
2. 3. mounting screws (not provided) on the wall, leaving 1/8” away from the wall. Align hood-mounting bracket to the screws on the wall and hook hood into place as shown in Figure 11. Tighten screws to secure hood to the wall. For safety purposes, extra knockout holes on the back of the hood are provided. Knockout the holes. Remove the baffle filters and attach screws to the wall by accessing underneath the hood.
7. 8. 9. 10. all joints secure and air tight as shown on Figure 14. To convert ductwork to 7” round, attached 7” round adapter (provided) to the 6” round plastic exhaust. Slide the inner duct cover up 2 inches before sliding the entire duct cover onto the hood. Refer to Figure 15. Adjust the height of the inner duct cover to the duct cover-mounting bracket. Secure the inner duct cover with two (4x8 mm) screws (provided).
OPERATION INSTRUCTIONS This KOBE hood is equipped with four electronic controls with a 10-second standby startup & 30second delay shutoff, two powerful centrifugal turbine impellers with baffle filters, and two bright 12-volt 20-watt halogen lights. The four electronic controls are Light Control, Speed Control A, Speed Control B and the Power Control (On/Off). Refer to Figure 19. Figure 19 Light Control Power Control Speed Control B Speed Control A TURN ON: Press Power Control (On/Off) button once.
MAINTENANCE For the optimal level of operation, clean the range hood surface and baffles regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve its fine appearance. 1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth. 2. If hood looks splotchy (stainless steel hood), use an orange base cleaner to clean the surface of the hood. Avoid cleaner to get on the control switches.
SPECIFICATIONS MODEL / SIZE CH9130SQB / 30” CH9136SQB / 36" CH9142SQB / 42” CH9148SQB / 48” COLOR # 304 Commercial Grade Stainless Steel CONSUMPTION / AMPERE CH9130SQB – 232W / 2.21A CH9136SQB – 232W / 2.21A CH9142SQB – 253W / 2.38A CH9148SQB – 258W / 2.
MEASUREMENTS & DIAGRAMS All measurements in ( ) are millimeters. All inch measurements are converted from millimeters. Inch measurements are estimated. - FOR UNDER THE CABINET MODEL NO.: CH9130SQB MODEL NO.
***Rear Knockout Holes MODEL NO.: CH9130SQB MODEL NO.
PARTS LIST MODEL NO.: CH9130SQB CH9136SQB CH9142SQB CH9148SQB NO. 1 2 3 4 DESCRIPTION 7” Round Adapter 6” Round Plastic Exhaust Plastic Plate Hood Casing 5 6 7 8 9 10 A Halogen Light Unit (12V 20W Max.
(Optional Duct Cover) ORIGINAL KIT NO. DESCRIPTION 01 Duct Cover-Mounting Bracket 02 Screw (TS 4 x 8 mm) 03 Duct Cover 04 Hood-Mounting Bracket 05 Screw (3/16” x 3/8”) 06 Rubber Stand 07 Screw (TS 4 x 8 mm) MODEL /SIZE RA1020DC RECIRCULATING KIT NO.
MODEL NO.
MODEL NO.
CIRCUIT DIAGRAM MODEL NO.
MODEL NO.
DISCLAIMER 1. CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT. REQUEST NAME AND SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. Failure to do so may result in the denial of your claim. The carrier will furnish you with necessary forms for filing a claim.
WARRANTY WARRANTY CERTIFICATE KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part, which its examination shall disclose to be so defective.
traveling expenses and any costs of transporting the range hood or parts thereof to and from the dealer or Service Agent 4) The purchaser must produce proof of purchase together with this warranty certificate when making the claim. 5) Damages caused during shipment are not covered under our warranty. CONSEQUENTIAL DAMAGE The warrantor is not responsible for any consequential damage. SOME STATES DO NOT ALLOW THE EXCLUSION OF CONSEQUENTIAL DAMAGE SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.
PRODUCT REGISTRATION Register Your Product! Any covered failure occurring within two years of original purchase arising from defective workmanship or material in manufacture will be repaired or at our option the unit will be replaced free of charge by an authorized KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection.
