EasyShare 5300 All-in-One Printer User’s Guide
Eastman Kodak Company Rochester, New York 14650 © Eastman Kodak Company, 2008 P/N 1K3234 Kodak and EasyShare are trademarks of Eastman Kodak Company. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks is under license. ©1989-2007 I.R.I.S.
Table of Contents Product Overview.................................................................................................................................... 1 Main Components.............................................................................................................................................. 1 Control Panel Layout......................................................................................................................................... 2 Status Lights..........
Table of Contents Scan ........................................................................................................................................................ 65 Scan with Control Panel................................................................................................................................. 65 Maintenance ......................................................................................................................................... 69 General Care...........
1 Product Overview Product Overview The Kodak EasyShare 5300 All-in-One (AiO) Printer allows you to print, copy, and scan photos or documents. Many functions can be operated directly from the Control Panel. You can buy optional accessories to enhance your Kodak EasyShare AiO experience.
Chapter 1 Control Panel Layout Number Name Description 1 LCD display Displays photos, messages, status, and menus. 2 Zoom + button When in Photo Preview mode, magnifies the photo to 1.5X. Subsequent presses zoom in 0.5X increments to a maximum of 5X. When in Multiview, displays the current photo in preview mode. 3 Proofsheet button When there are pictures on an inserted memory card or connected USB host device, pressing Proofsheet displays the Proofsheet menu.
Product Overview Number Name Description 11 Attention Light On or flashing for an error or warning condition. 12 Start button Starts a copy, print, or scan operation. 13 Cancel button Cancels the current operation. 14 4-way Navigation Used to navigate Up a, Down b, Left _, and Right `. button 15 Menu button Displays the main menu screen. 16 Scan button Press to enter Scan mode. Lit when in Scan mode. 17 Rotate button Rotates picture on the display, clockwise, 90 degrees.
Chapter 1 Power Light on Power Cord Light Status Cause Action/Solution Power cord light is off. The printer to power supply cord is not properly connected to the Power Supply. Reseat the printer to power supply cord. The power supply to your wall outlet cord is not properly connected to your wall outlet. Reseat the Power Supply to your Wall Outlet Cord. You do not have the appropriate power available at your wall outlet.
Product Overview On/Off Light Light Status Cause Action/Solution Light is off. The printer is turned off. Press the On/Off button to turn the printer on. The Printer does not have power applied. Check the light on the power cord. The printer needs attention. Check to see if the Photo Tray light is on. If the Photo Tray light is on for more that 20 seconds and the On/Off light does not come on, disconnect the power for 5 seconds and reconnect the power.
Chapter 1 Photo Tray Status Light Light Status Cause Action/Solution Photo tray light is Off. The photo tray is not engaged. Push the photo tray in to engage if you want to print 4 x 6 inch pictures. The printer is not turned on. Press the On/Off button to turn the printer on. The photo tray is engaged. Pull the photo tray out to disengage if you do not want to print 4 x 6 inch pictures. The printer is powering up. None: Please wait and allow the printer to complete the initialization process.
Product Overview Attention Light Light Status Cause Action/Solution Light is off. No Error. None Light is blinking steady. Recoverable Error. Paper jam while printing. Main tray empty. Photo tray empty. Carrier stall during pick. Media size mismatch. Media type mismatch. Paper jam during pick. Carrier stall while printing. Change color ink cartridge. Change black ink cartridge. Color ink cartridge not readable. Black ink cartridge not readable. Change both ink cartridges. Printhead not calibrated.
Chapter 1 Card Slot Light Light Status Cause Action/Solution Light is off. An SD/MMC card is not inserted or is improperly inserted in the card slot. Remove and reinsert the SD/MMC card. Light is on. An SD/MMC card is properly inserted in the card slot. None Light blinks green. Slow blink: The internal card reader is initializing or communicating with the printer. None Fast blink: There is a card or communication error.
Product Overview Default Display Settings Default settings are provided for each option. If you make changes to the settings, the changes remain as long as you do not change modes. You can save the settings in each mode by navigating to Save Settings and pressing OK. You may reset options to the master defaults by going to the main menu and selecting Reset All Settings. Photos The LCD screen displays JPG images when you insert a memory card, camera, or USB device.
Chapter 1 Supported Memory Cards Your Kodak EasyShare AiO can read the following memory cards. xD-Picture Card Memory Stick Memory Stick Pro Secure Digital Card/MultiMediaCard Compact Flash type I and type II, including microdrives Your EasyShare AiO also supports the following memory cards with Memory Stick and SD/MMC card slot adapters you can purchase. Memory Stick Duo miniSD MicroSD (TransFlash) The Memory Card light is a green LED located near the memory card slots.
Product Overview AiO Home Center (Macintosh) The AiO Home Center software is an application that runs on the computer. It enables you to configure your AiO printer from the computer. After installation, you can run Home Center from the Printer Setup Utility by selecting your Kodak AiO Printer in the Printer List and clicking the Utility icon.
Chapter 1 12 Kodak EasyShare 5300 AiO
2 Getting Started Getting Started It is important to find a good location for your AiO Printer. Place the printer on a clean flat surface, in a dry location, and out of direct sunlight. Make sure the printer has proper ventilation. Avoid areas where ventilation ducts, open doors, or high traffic might expose the EasyShare AiO and paper to high levels of dust and debris. Airborne particles can affect picture quality.
Chapter 2 3 Remove the printhead from its bag. 4 Remove and discard the clear plastic casing and the orange protective cap. 5 Place the printhead into the carriage. 6 Push against the back wall of the printhead until it clicks into place. 7 Install the ink cartridges.
Getting Started Install Ink Cartridges After installing the printhead, you need to install the black and color ink cartridges. 1 Printhead 2 Color ink cartridge 3 Black ink cartridge 1 Tear open the black ink cartridge bag at the notch and remove the ink cartridge. IMPORTANT: Insert the ink cartridge immediately to prevent any drying of the ink. 2 Remove and discard the orange cap. IMPORTANT: Handle ink cartridge carefully to avoid ink transfer. 3 Insert the black ink cartridge into the printhead.
Chapter 2 4 Press down on the ink cartridge until you hear it snap into position. 5 Tear open the color ink cartridge bag at the notch and remove the ink cartridge. 6 Remove and discard the orange cap. 7 Insert the color ink cartridge into the printhead. 8 Press down firmly on the cartridge until you hear it snap into position. 9 Close the printer access door. NOTE: For the best quality prints, store ink cartridges in a location where the temperature does not exceed 85° F (30° C).
Getting Started 1 Remove the door on the back of the printer by pressing in on the two latches and pulling out. 2 Insert the bottom of the duplexer into the printer and press the top in until it clicks. You can control how long the printer waits before a sheet is flipped by the duplexer with the AiO Home Center (See General Settings). Startup When you power on your Kodak EasyShare All-in-One, status information is displayed on the LCD.
Chapter 2 Menus The Kodak EasyShare AiO menus are accessed by the Menu, Photo, Copy, Scan, and Help buttons.
Getting Started Date and Time OK Year Month Day Hour Minute Language _ or ` Reset all Settings OK _ or ` _ or ` _ or ` _ or ` _ or ` 2006-2099 January-December 1-31 0-24 0-60 Photo Button Layout _ or ` Borderless Bordered 2 per Page 3 per Page 4 per Page 9 per Page Index 2x2 Poster 3x3 Poster Quantity Color Quality _ or ` _ or ` _ or ` 4x4 Poster 1 - 99 Color Black & White Normal Best Save Settings _ or ` Draft No Yes User’s Guide 19
Chapter 2 Copy Button Quantity Color Quality _ or ` _ or ` _ or ` 1 - 99 Black & White Color Normal Draft Output _ or ` Best Same Size Fit to Page Scale Percent Size _ or ` Photo Layouts Output = Scale Percent 10 - 500 Output = Photo Layouts Borderless Bordered 2 per Page 3 per Page 4 per Page 9 per Page Index 2x2 Poster 3x3 Poster Brightness Preview Save Settings _ or ` _ or ` _ or ` 4x4 Poster -3 to +3 No Yes (Photo Layouts only) No Yes 20 Kodak EasyShare 5300 AiO
Getting Started Scan Button Scan What Scan To _ or ` Document _ or ` Photo File Application Memory Card Application Save Settings _ or ` _ or ` List of applications No Yes Help Button Installing Ink Cartridges Making a Copy Making a Photo Making a Scan Calibrating Printer OK OK OK OK OK Demo Sheet You can print a sample page on US Letter or A4 size paper to evaluate print quality.
Chapter 2 Transfer Photos After you take photos with your digital camera, you can print them immediately or save them directly to your computer. You can transfer from memory cards, PTP cameras, and USB mass storage devices. 1 Insert a Memory Card into the appropriate slot or connect a camera to the USB Port. WARNING: Never attempt to remove a memory card while it is being accessed. Doing so can damage files on the card.
Getting Started The default setting for using a detected DPOF file is Yes. 1 Press Menu to display the main menu. 2 Press b to select Photo Print Settings. 3 Press OK. 4 Press b to select Use Print Order if Found. 5 Press _ or ` to change the setting. 6 Press OK. Scene Balance Your EasyShare AiO is configurable to apply automatic scene balance improvements (brightness) for photos printed on the AiO from camera cards and USB connected devices. The default is to apply the scene balance improvements.
Chapter 2 Minutes to Standby When the Kodak EasyShare All-in-One is idle for the standby power setting timeout period, it enters the Standby state. The On/Off indicator remains lit, but power consumption is reduced. When in the Standby state, any activity such as a single button press, or inserting camera card, brings the EasyShare AiO out of the Standby state and returns it to the Ready state. You can set the standby timeout from 10 – 30 minutes. The default setting is 15 minutes.
Getting Started Set Language You can select the language the EasyShare AiO uses for the LCD display. 1 Press Menu to display the Main Menu. 2 Press b until Language is displayed. 3 Press OK to go to the Select Language menu. 4 Press b until the language you want is selected. 5 Press OK. Reset All Settings You can restore the original factory settings to your Kodak EasyShare All-in-One. NOTE: Restoring the factory defaults will not change the date and time information you set.
Chapter 2 26 Kodak EasyShare 5300 AiO
3 Handling and Loading Paper Handling and Loading Paper Use the following guidelines when handling paper. To avoid fingerprints, handle the paper by the edges as much as possible. Avoid touching the glossy side of photo paper. Keep the input and 4x6 paper trays closed to keep out dust and debris. Store paper flat. Keep paper away from direct sunlight, and out of high-temperature environments (such as a vehicle parked in the sun).
Chapter 3 You can copy or scan oversized originals by completely removing the lid from your EasyShare AiO. To remove the lid, lift the lid to the open position, grasp the sides of the lid, and then pull the lid upward. Your EasyShare AiO functions normally with the lid removed. Replace the lid by inserting the tabs on the hinge back into the appropriate slots. Load Main Tray You can load the main paper tray with various types of paper from 3 to 8.
Handling and Loading Paper 4 Slide the paper-width and paper-length guides inward until they stop at the edges of the paper. 5 Lower the output tray. 6 Pull the extender tray out.
Chapter 3 Load Photo Tray You can load up to 20 sheets of 10 mil thick 4x6 inch (101x150 mm) photo paper into the photo tray. TIP: To avoid fingerprints, handle the paper by the edges or by the perforated tabs. Avoid touching the glossy side of the paper. 1 Lift the photo tray lid. 2 Slide the photo tray towards you until it stops. NOTE: When the photo tray is disengaged, the main paper tray is active. 3 Insert the stack of photo paper into the photo tray glossy side down.
Handling and Loading Paper 5 Close the photo tray lid. Load Envelopes You can load plain envelopes into the main input tray of your Kodak EasyShare AiO. Do not use envelopes with cutouts or cellophane windows. 1 Lift the output tray. 2 Remove any paper in the input tray. 3 Insert one or more envelopes face down with the envelope flaps to the left. 4 Slide the stack of envelopes forward until it stops. 5 Slide the paper guides inward against the stack of envelopes until they stop.
Chapter 3 6 Close the output tray. Load Labels Use letter or A4 (designed for use with ink jet printers) label sheets. 1 Ensure that none of the pages are sticking together. 2 Place a stack of label sheets on top of standard paper in the input tray, label side down.
4 Print Print The memory card slots accept most of the popular memory cards (see Supported Memory Cards). When you insert a memory card into the card slot, connect PTP camera, or USB flash drive, the last photo is displayed on the LCD display. When you press the Photo button the Photo Print menu is displayed. The Photo button toggles between displaying photos and the Photo Print menu. CAUTION You can only use one device (USB or Memory card) from which to print.
Chapter 4 Two-sided Printing You can print on both sides of the paper. Watermark You can select or create a background watermark. Print Photos from a Camera 1 Connect your camera to the EasyShare AiO. The PictBridge logo is displayed on the LCD. 2 Load the photo tray with photo paper (See Load Photo Tray in Chapter 3). 3 Use your camera to select and print photos.
Print Index Print The purpose of an index print is to catalog contents of a memory card or USB flash drive. An Index print contains the following: Sequence numbers for the relative position of each photo within the defined set of photos, incrementing from 001 and continuing progressively across all pages of a multi-page index print. 8x10 Index prints are 7/8 inches wide with 1/8 inch white space between photos. The filename is displayed below each thumbnail image.
Chapter 4 Print Photos from a Proofsheet A proofsheet is a simple and convenient way to select photos and make prints directly from a camera or memory card without the need for a computer. Proofsheet printing is a two step process. In the first step, you connect a PTP camera or insert a memory card and print a proofsheet. In the second step, you select pictures to print from the proofsheet and then scan the proofsheet into the EasyShare AiO.
Print If a DPOF file is detected when you insert a memory card, the EasyShare AiO displays a message asking if you want to print tagged images. Bluetooth Printing Bluetooth is a short-range radio technology that enables wireless connectivity between electronic devices. This feature supports an optional Kodak USB Bluetooth Adapter that accepts JPEG/EXIF image file types from the following types of Bluetooth enabled devices.
Chapter 4 Panoramic photos Panoramic images are detected based on the aspect ratio of the image. A panoramic image is displayed in a "fit to page" manner with blank space above and below the image. The crop box is adjusted for a 300 x 100 mm (12 x 4") aspect ratio and initially encompasses the entire image. If panoramic images are selected for printing, the AiO printer prints all of the panoramic images after all other images have printed.
Print User’s Guide 39
Chapter 4 Set Print Layout 1 Press Photo. The Print menu is displayed with Layout selected. 2 Press _ or ` to change the print layout. 3 Press OK to set the selected layout and continue to set options, press Photo to preview, or Start to print.
Print 3.
Chapter 4 4x6 Inch Paper 42 1 per page borderless 1 per page bordered 2 per page 3 per page 4 per page 9 per page Kodak EasyShare 5300 AiO
Print 5x7 Inch Paper 1 per page borderless 1 per page bordered 2 per page 3 per page 4 per page 9 per page User’s Guide 43
Chapter 4 8x10 Inch Paper 44 1 per page borderless 1 per page bordered 2 per page 3 per page 4 per page 9 per page Kodak EasyShare 5300 AiO
Print US Letter 1 per page borderless 1 per page bordered 2 per page 3 per page 4 per page 9 per page User’s Guide 45
Chapter 4 Panoramic 46 Kodak EasyShare 5300 AiO
Print A4 Paper 1 per page borderless 1 per page bordered 2 per page 3 per page 4 per page 9 per page User’s Guide 47
Chapter 4 A5 Paper 48 1 per page borderless 1 per page bordered 2 per page 3 per page 4 per page 9 per page Kodak EasyShare 5300 AiO
Print A6 Paper 1 per page borderless 1 per page bordered 2 per page 3 per page 4 per page 9 per page User’s Guide 49
Chapter 4 B5 Paper 1 per page borderless 1 per page bordered 2 per page 3 per page 4 per page 9 per page Setting Print Options Before you print photos you may want to change the following default settings.
Print The Photo Print menu contains parameters that allow you to specify other options. Set Number of Prints You can increase the number of prints of each photo from the Photo Print menu. The default is 1 print. 1 On the Print menu, select Quantity. 2 Press _ or ` to change the print quantity. 3 Press OK to set the selected layout and continue to set options, press Photo to preview, or Start to print. Set Color You can print in color or black-and-white. Printing in color is the default.
Chapter 4 Previewing Photos The Print Preview screen contains a crop box, displays the current photo number on the card or USB host device, and the total number of photos on the card or device. It displays a checkbox indicating whether or not the currently displayed photo has been selected for printing. A checkmark is placed in the checkbox when the photo is selected along with the number of copies to be printed.
Print Zoom Photos 1 Insert a memory card into the appropriate slot, a mass storage device into the USB port, or connect a digital camera to the USB port. The first photo is displayed. 2 Press Zoom + to enlarge the photo in .25X increments up to 5X magnification. Pressing Zoom – decreases magnification in .25X increments down to 1X. 3 Use the 4-way Navigation button to display the part of the picture you want to print. 4 Press OK when finished.
Chapter 4 Multiview The Multiview screen shows thumbnails of nine photos. The current photo number and the total photo number are also displayed. 1 Insert a memory card into the appropriate slot, a mass storage device into the USB port, or connect a digital camera to the USB port. The last photo is displayed. 2 Press Zoom - to enter Multiview. The current photo is indicated by a red selection box. 3 Use the 4-way Navigation button to move the red selection box to another photo.
Print User’s Guide 55
5 Copy Copy The Kodak EasyShare AiO allows you to produce high-quality color and black-and-white copies on a variety of paper types, including transparencies. Once copying has started, you may at any time abort a copy operation by pressing the Cancel button. Copy with Control Panel Pressing Copy displays the copy menu where you can set copy options, preview copies after scanning, and make copies. When copying from the Control Panel, you can choose from the following outputs.
Chapter 5 Same Size Copy The copy is the same size as the original and is the default copy setting. Cropping will occur if the original is larger than the paper size. The copy will contain white space if the original is smaller than the paper size. 1 Load your original face down on the right front corner of the scanner glass. 2 Press Copy to display the Copy menu. 3 Press b to select Output. 4 Press _ or ` to select Same Size. 5 If desired, make changes to the following copy options with the Copy menu.
Copy Fit to Page Copy The image is copied and fit to the paper size loaded. There may be cropping on the sides or top/bottom depending on the difference in the aspect ratios of the image and the page size. 1 Place your original face down on the right front corner of the scanner glass. 2 Press Copy to display the Copy menu. 3 Press b to select Output. 4 Press _ or ` to select Fit to Page. 5 If desired, make changes to the following copy options with the Copy menu.
Chapter 5 Scale Percent Copy The default copy scale is 100%, however you can scale copies from 10% to 500%. Scaling is anchored to the upper left corner of the original. 1 Place your original face down on the right front corner of the scanner glass. 2 Press Copy to display the Copy menu. 3 Press b to select Output. 4 Press _ or ` to select Scale Percent. 5 Press b to select Size. 6 Press _ or ` to change the scaling. 7 If desired, make changes to the following copy options with the Copy menu.
Copy Photo Layout Copy You can set the layout for making copies of photos on your Kodak EasyShare All-in-One. The following layouts are supported. Borderless (default) Bordered 2 per Page 3 per Page 4 per Page 9 per Page 2x2 Poster 3x3 Poster 4x4 Poster 1 Place your original face down on the right front corner of the scanner glass. 2 Press Copy to display the Copy menu. 3 Press b to select Output. 4 Press _ or ` to select Photo Layouts. 5 Press b to select Size. 6 Press _ or ` to change the layout.
Chapter 5 Setting Copy Options You can set the following copy options with the Control Panel Copy menu. Quantity Color Quality Output/Size (See Same Size Copy, Fit to Page Copy, Scale Percent Copy, or Photo Layout Copy) Brightness Preview Save Settings Set Number of Copies You can set the number of copies to make from the copy menu. The default is 1 copy. 1 On the Copy menu, select Quantity. 2 Press or hold _ or ` to change the number of copies you want to make.
Copy Change Brightness You can change the brightness of copies with -3 being the darkest and +3 the lightest. 1 If the Copy menu is not displayed, press Copy. 2 Press b until Brightness is selected. 3 Press _ to darken or ` to lighten. 4 Press OK to set and continue setting options, or Start to copy. Set Preview Copy Preview allows you to preview your originals before making copies. The Copy Preview screen shows the scanned image that you can zoom or crop (see Zoom and Crop).
Chapter 5 Zoom and Crop To zoom and crop a photo before making a copy you must be in Preview mode (see Turning Copy Preview On). 1 With Preview set to Yes on the Copy menu, press Start to enter Preview mode. The photo on the glass is scanned and displayed with a crop box. 2 Press Zoom + to enlarge the photo in .25X increments up to 5X magnification. Pressing Zoom – decreases magnification in .25X increments down to 1X.
6 Scan Scan You can start a scan from the Kodak AiO Control Panel or your computer. Scan with Control Panel Pressing Scan places the Kodak EasyShare AiO in Scan mode and displays the Scan menu on the screen. Save Scan Settings When you change scan settings from the control panel, the settings apply only to the current scan job. To apply scan settings to all future scan jobs, you can save your changes. 1 Press Scan to display the Scan menu. 2 Change the desired Scan settings.
Chapter 6 Scan to Application The Home Center software enables you to maintain a list of scan destination applications. 1 Place a photo or photos face down on the scanner glass. 2 Press Scan to display the Scan menu. 3 Press _ or ` to select Photo. 4 Press b to select Scan To. 5 Press ` to select Application. 6 Press b to until Application is selected. 7 Press _ or ` to select another application. 8 Press Start. Scan to Memory Card 1 Insert a Memory Card into the appropriate card slot.
Scan Scan to File 1 Load your original face down on the right front corner of the scanner glass. 2 Press Scan to display the Scan menu. 3 Press _ or ` to select Document. 4 Press Start. The document is scanned and saved based on the Kodak AiO Home Center scan document settings (see Scan Document Settings). Scan to Application 1 Load your original face down on the right front corner of the scanner glass. 2 Press Scan to display the Scan menu. 3 Press _ or ` to select Document.
Chapter 6 Scan to Memory Card 1 Insert a Memory Card into the appropriate card slot. WARNING: Never attempt to remove a memory card while it is being accessed. Doing so can damage files on the card. You can safely remove a card only when the status light next to the slots is not blinking. 2 Load your original face down on the right front corner of the scanner glass. 3 Press Scan to display the Scan menu. 4 Press _ or ` to select Document. 5 Press b to select Scan To. 6 Press _ or ` to select Memory Card.
7 Maintenance Maintenance The Kodak EasyShare All-in-One requires little maintenance. However, you should clean the glass and lid backing to remove dust and fingerprints. Fingerprints and other debris on the glass or lid backing could slow down performance and affect the accuracy of scanning. This section covers the Settings menu, printhead installation, printhead calibration, checking ink levels, and changing ink cartridges. General Care IMPORTANT: Always disconnect the power before cleaning.
Chapter 7 Clean the Scanner Glass To ensure that your copies and scans remain clear, keep the scanner glass and lid backing clean and dust the exterior. 1 Turn off the EasyShare AiO and raise the lid. 2 Clean the glass with a soft cloth or sponge slightly moistened with a nonabrasive glass cleaner. WARNING: Do not use abrasives, acetone, benzene, or carbon tetrachloride on the glass, since they can damage it. Do not place or spray liquid directly on the glass.
Maintenance 4 Press Start to begin printing. Firmware Upgrade You can update the firmware in your EasyShare AiO with the most recent available from the Home Center software. This requires an internet connection. 1 Click the Help button to open the Help panel. 2 Under General Links, click Maintenance. 3 Click Firmware Upgrade. Ink Cartridges Your Kodak EasyShare AiO uses separate black and color ink cartridges. The ink levels are displayed on the Control Panel and the printer software.
Chapter 7 1 Open the printer access door by lifting from the front center of the unit. The ink tanks are located in the print head. 1 Print head 2 Color ink cartridge 3 Black ink cartridge 2 Wait until the printhead is idle and silent, then pinch the pinch latch on the old ink cartridge with your thumb and forefinger and lift it out of the print head. 3 Open the box of the new ink cartridge. 4 Remove the bagged ink cartridge from the box and tear open the bag at the notch and remove the ink cartridge.
Maintenance 6 Slide the ink cartridge into the printhead. 7 Press down on the tab until you hear a click and feel the latch snap into position. 8 Close the printer access door. Printhead The printhead dispenses the ink from the ink cartridges onto the paper. Printer maintenance involves: Calibration Clean the printhead Calibration The Kodak EasyShare AiO performs a calibration every time you install or replace a printhead.
Chapter 7 To calibrate from control panel 1 Load the main tray or photo tray with photo paper. IMPORTANT: If you don't have any photo paper, you can use plain paper, but photo paper is highly recommended for calibrations. 2 Press Menu. 3 Press b until Calibrate Printer is selected. 4 Press OK. A new screen appears with Print Calibration Page selected. 5 Press Start and follow the instructions on the LCD screen to complete the calibration.
Maintenance 3 Wait until the printhead is idle and silent, then pinch the pinch latch on the ink cartridge with your thumb and forefinger and lift it out of the print head. Remove both ink cartridges. 4 Unlatch the printhead by pressing the button in the upper-left corner of the carriage. 5 Remove the old printhead. 6 Remove the printhead from its bag. 7 Remove and discard the clear plastic casing and the orange protective cap.
Chapter 7 8 Place the printhead into the carriage. 9 Push against the back wall of the printhead until it clicks into place. 10 Reinstall the ink cartridges.
8 Support Support If you have a problem with your AiO printer, refer to the Troubleshooting topics in this book. Additional technical information is available in the ReadMe file located on the Kodak EasyShare software CD. For online support, visit www.kodak.com/go/support. Contact Kodak Kodak Resource Center www.kodak.com/go/resourcecenter Printer Get support for your product (FAQs, troubleshooting information, etc.). www.kodak.
Chapter 8 Kodak along with proof of the purchase price paid. Repair, replacement, or refund of the purchase price are the sole remedies under this warranty. If replacement parts are used in making repairs, those parts may be remanufactured. or may contain remanufactured materials. If it is necessary to replace the entire Product, it may be replaced with a remanufactured Product.
Support Telephone Customer Support If you have questions concerning the operation of your EasyShare software, Home Center software, or EasyShare AiO, you may speak with a customer support representative. When you call, please have the following information available.
Chapter 8 Customer Support Phone Numbers Australia 1800 147 701 Austria 0179 567 357 Belgium 02 713 14 45 Canada 1 800 465 6325 Denmark 3 848 71 30 Finland 0800 1 17056 France 01 55 1740 77 Germany 069 5007 0035 International Toll Fax +44 131 458 6962 International Toll Line +44 131 458 6714 Ireland 01 407 3054 Italy 02 696 33452 Japan 03 5540 9002 Mexico 01 800 288 56325 Netherlands 020 346 9372 New Zealand 0800 440 786 Norway 23 16 21 33 Portugal 021 415 4125 Spain 91
Support Bluetooth Device not Recognized Probable Cause 1 The internal Bluetooth radio in the device may be turned off. Corrective Action Make sure the device is on and within range of the Bluetooth radio signal (30 ft., or 10 meters). NOTE: The Bluetooth technology enabled device must use an BIP, OPP, or FTP profile. Probable Cause 2 Sending device requires a PIN. Corrective Action Enter a PIN of 1111 into the sending device.
Chapter 8 1 Disengage the Photo tray. 2 Remove the paper from the paper tray(s). Carefully "fan" the paper to keep the sheets from sticking together. 3 Reload the paper tray(s). Do not overfill. 4 Re-engaged the Photo tray, then press Start to resume printing. No Communication with Computer Your EasyShare AiO is not connected to your computer. 1 Make sure you are using the proper USB Cable. 2 Check the connection from your computer to your AiO printer.
Support Check the paper 1 Disengage the Photo tray. 2 Inspect the paper and make sure paper no sheets are damaged in any way. Reload with new paper if necessary. 3 Carefully "fan" the paper to keep the sheets from sticking together. 4 Reload the paper tray(s). Do not overfill. 5 Engage the Photo tray, if printing 4 x 6 Photo’s, then press Start to resume printing. Paper Jam The paper did not advance or was not picked properly from the paper tray. 1 Open the paper trays and remove the paper supply.
Chapter 8 Transfer Pictures Failure Nothing happens when you try to transfer pictures to the computer. 1 Press the Transfer button, on the printer. 2 Check the power and USB connections from the printer to the computer. 3 If you are trying to transfer pictures from a memory card and a PictBridge camera is connected, remove it. 4 Close unnecessary software applications, and minimize remaining application windows. Follow any messages on the screen that may have been hidden by other windows.
Support Photo Print Smudged Fingerprints may be on glossy side of paper. Handle paper by the edges. PictBridge Camera not Detected 1 Check the USB connections from the PictBridge compatible camera or device to the printer. 2 If disconnected, reconnect the USB cable from the PictBridge compatible camera or device to the printer. 3 Make sure there is at least one picture in the PictBridge compatible camera or device’s internal memory or memory card.
Chapter 8 Probable Cause 2 More than one type of paper is loaded. Load only one type of paper. Print Spotted Paper may be dirty. Use a dry, lint-free cloth to wipe clean. For excessive dirt or debris, thoroughly clean the paper tray, and load new paper. NOTE: Keep paper tray covers closed to keep dust and debris from collecting on the paper or inside the printer. Print Too Dark Try re-taking the picture with the flash on, or move within the flash range of the camera.
Support Check the paper 1 Disengage the photo tray if engaged. 2 Check the paper access on the back of the printer. 3 Remove any loose paper from the printer. 4 Inspect the paper supplies and reload with new paper if necessary. 5 Carefully "fan" the paper to keep the sheets from sticking together. 6 Reload the paper trays. Do not overload. 7 Re-engage the photo tray, if desired, and then press Start to resume printing.
Chapter 8 Copies too Light or Dark The brightness setting for copies is set too light or dark. Adjust the brightness setting for copies See Change Brightness or Copy Settings. Copy Cut Off The original is larger than the paper loaded. When the original is larger than the paper loaded, use the Fit to Page option to reduce your original to the size of the paper loaded. Scan Troubleshooting Scan Fails Probable Cause 1 Your computer is not turned ON. Turn on your computer.
Support Scanned Image Blank Your original is not placed correctly on the scanner glass. Place your original face down on the right front corner of the scanner glass. Proofsheet Scan Unsuccessful Probable Cause 1 The scanner glass is dirty. Make sure the scanner glass is completely clean or the proofsheet might not scan properly (see Clean the Scanner Glass). Probable Cause 2 Memory Card or Camera Changed Make sure the same memory card inserted or camera connected you used to print the proofsheet.
Chapter 8 90 Kodak EasyShare 5300 AiO
9 Appendix Appendix All-in-One Specifications B&W plain paper print speed (Draft/Normal/Best) 32 / 10.5 / 5 ppm Color plain paper print speed (Draft/Normal/Best) 22 / 6 / 3 ppm Photo print speed - 4X6 Kodak Studio Gloss Photo print speed - 8X10 Kodak Studio Gloss 2.14 ppm [28 sec/print] 0.86 ppm [70sec/print] B&W plain paper copy speed (Draft/Normal/Best) 30 / 10 / 5 ppm Color plain paper copy speed (Draft/Normal/Best) 20 / 6 / 3 ppm Scan Resolution 1200 dpi Size 18.8”W x 14.7”D x 8.8”H (47.
Chapter 9 Paper Types The following tables show the paper types and sizes the Kodak EasyShare AiO supports for copying and printing. Supported Paper Types Plain paper 20 to 24 lb (64 to 90 gsm) Photo paper 10 mils Card Stock 110 lb index max (200 gsm) Envelopes 20 to 24 lb (75 to 90 gsm) Transparency All commercially available inkjet varieties (with or without a widestripe.) Labels All commercially available inkjet varieties on 8.
Appendix Supported Paper Sizes Usage Size Tray Document page sizes Labels A4 (210x297 mm) A5 (148x210 mm) A6 (105x148 mm) US Executive (7.25x10.5 in.) (184x266 mm) US Legal (8.5x14 in.) (216x356 mm) US Letter (8.5x11 in.) (216x280 mm) Custom sizes Main Index Card Stock 3x5 in. index cards (76.2x127 mm) 4x6 in. index cards (101x152 mm) 5x7 in. index cards (127x178 mm) Main Transparency Iron-on Transfers A4 (210x297 mm) US Letter (8.5x11 in.) (216x280 mm) Main Envelopes B5 (6.92x9.84 in.
Chapter 9 Safety Read and follow these cautions and warnings before using KODAK products. Always follow basic safety procedures. Follow all warnings and instructions marked on the equipment. Parts CAUTION Do not disassemble this product; there are no user-serviceable Part(s) inside. Refer servicing to Kodak qualified service personnel. WARNING Keep out of reach of children. Ink is harmful if swallowed.
Appendix CAUTION Do not use your EasyShare AiO near water, or spill liquid on it. WARNING Do not place your EasyShare AiO on an unstable cart, stand, bracket, or table. Injury to persons and damage to the equipment may occur. Environment CAUTION Excessive dust levels may damage internal parts. CAUTION Unplug the equipment from the wall outlet before cleaning.
Chapter 9 Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Where shielded interface cables have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulation.
Appendix This equipment has been certified by the manufacturer in accordance with Directive 1999/5/EC (Annex II) for Pan-European single-terminal connection to the public switched telephone network (PSTN). However, due to differences between the individual PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.
Chapter 9 98 Kodak EasyShare 5300 AiO
Glossary Glossary A ADF: Automatic Document Feeder AES: Advanced Encryption Standard C CHAP: Challenge Handshake Authentication Protocol D dBa: Decibel measured with a "weighting filter" dBm: A measured power level in decibels relative to 1mW. Dongle: A small electronic device that plugs into a USB port. DPOF: Digital Print Order File - An ASCII order file that you can generated in a camera that supports DPOF. DPOF files enable you to request simple reprints of the photos in the file.
Glossary W WEP: Wired Equivalent Privacy Wi-Fi: Wireless Fidelity WLAN: Wi-Fi Local Area Network WPA: Wi-Fi Protected Access 100 Kodak EasyShare 5300 AiO
Index Index 2 2-Sided Printing Accessory .....................................16 A A6 Paper......................................................................49 Audio Feedback......................................................... 23 B B5 Paper.......................................................................50 Bluetooth ...............................................................37, 81 Borderless ................................................................... 87 Brightness ................
Index R Requirements.............................................................. 91 Reset .............................................................................25 S Safety ........................................................................... 94 Same Size.....................................................................58 Sample Page................................................................ 21 Scale Percent ............................................................. 60 Scan........
