User Guide

Operating VRS
VRS User’s Manual
27
Note When you select the first level of accelerated scanning, the image quality is
virtually equivalent to non-accelerated scanning. However, higher levels of
acceleration affect the image quality. Not all scanners increase in speed when you
select accelerated scanning. If your scanner does not feature lower resolutions than
the resolution selected in your scan application, accelerated scanning will have no
effect.
Updating the VRS Administration Utility Dialog Box
Use these instructions to update the settings on the VRS Administration Utility tabs.
X To update the VRS Administration Utility settings
1 Right-click on the VRS taskbar icon to open the VRS menu.
2 From the VRS menu, select Admin Utility.
3 Select and adjust the settings for the following tabs:
• Warnings tab—Threshold. Type directly into the Threshold text box, or
click the arrows to select a new threshold setting. For more information,
refer to Warnings Tab on page 21.
• Warnings tab/Errors tab—Action. Define a VRS response to each
exception type by clicking in the Action option and selecting from the list.
For more information, refer to Action Options on page 25.
• Accelerated Scanning tab. Click and drag the slider to make your
selection. For details, refer to Accelerated Scanning Tab on page 26.
Table 2-5. Accelerated Scanning DPI Settings for the Fujitsu M3091DC and M3092DC
DPI Setting as
Defined in Scan
Application
Actual Scan DPI
Setting Level 1
Acceleration
Actual Scan DPI
Setting Level 2
Acceleration
Actual Scan DPI
Setting Level 3
Acceleration
Image Output
DPI Setting
300 240 150 100 300
240 200 150 100 240
200 150 100 75 200
150 150 75 75 150
100 75 75 75 100
75 75 75 75 75
