Dimensions Guide

Features
•
Vitreous China
•
Elongated Bowl
•
Comfort Height
®
•
AquaPiston
®
flushing system
•
Touchless Technology allows hands-free operation to actuate
the flush
•
Less seat and supply
•
1.28 gpf (4.8 lpf)
•
2-1/8" (54 mm) glazed trapway
•
10-1/2" (267 mm) x 7-7/8" (200 mm) water area.
Installation
•
12" (305 mm) rough-in
CSA B651
OBC
•
28-3/4" (730 mm) x 17-5/8" (448 mm) x 30-3/4" (781 mm)
Components
Product includes:
K-4309 Elongated Toilet Bowl
K-5692 Toilet Tank
Additional included component/s: Bowl, Tank, Tank Cover, and
Touchless Flush Kit.
Codes/Standards
ASME A112.19.2/CSA B45.1
DOE - Energy Policy Act 1992
EPA WaterSense
®
California Energy Commission (CEC)
ADA
ICC/ANSI A117.1
CSA B651
OBC
KOHLER
®
One-Year Limited Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
White0
Biscuit96
Almond47
DuneNY
Ice™ Grey95
SandbarG9
Black Black™7
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
12-1-2017 08:37
Cimarron
®
Comfort Height
®
Touchless Toilet
K-6418
