Dimensions and Measurements

ManualsBrandsKohler ManualsPlumbingK-6814-4-PB Polished Brass Iv Iv Georges Brass Ges Lever Handle Bidet Faucet Et

Features

•

Brass construction

•

Flexible connections for easy installation

•

Brass valve bodies

•

Quarter-turn washerless ceramic disc valves

•

Pop-up drain with lift rod and tailpiece

•

Available with cross or lever handles

•

Vertical spray

•

Fixture-mount transfer valve/vacuum breaker

Codes/Standards Applicable

Speciﬁed model meets or exceeds the following:

•

ASME A112.18.1/CSA B125.1

•

ASSE 1001

BIDET FAUCET

K-6814

Colors/Finishes

•

PB: Vibrant

Polished Brass

•

Other: Refer to Price Book for additional colors/ﬁnishes

Speciﬁed Model

Model Description

K-6814-3 Bidet faucet with cross handles ❑ PB ❑ Other ____

K-6814-4 Bidet faucet with lever handles ❑ PB ❑ Other ____

Optional Accessories

K-6792 IV Georges Brass accent kit (for K-6814-3) ❑ PB ❑ Other ____

K-6797 IV Georges Brass accent kit (for K-6814-4) ❑ PB ❑ Other ____

Product Speciﬁcation

Two-handle bidet faucet shall be of brass construction. Faucet shall feature brass valve bodies. Faucet shall feature quarter-turn

washerless ceramic disc valves. Product shall include ﬂexible connections for easy installations, pop-up drain with lift rod and

tailpiece, cross or lever handles, ﬁxture-mount transfer valve/vacuum breaker, and vertical spray. Faucet shall be Kohler Model

K-6814-_____-_____.

IV GEORGES BRASS

Page 1 of 2

113777-4-

USA/Canada: 1-800-4KOHLER

(1-800-456-4537)

www.kohler.com

Summary of content (2 pages)

PAGE 1
IV GEORGES BRASS® Features • • • • • • • • BIDET FAUCET K-6814 Brass construction Flexible connections for easy installation Brass valve bodies Quarter-turn washerless ceramic disc valves Pop-up drain with lift rod and tailpiece Available with cross or lever handles Vertical spray Fixture-mount transfer valve/vacuum breaker Codes/Standards Applicable Specified model meets or exceeds the following: • ASME A112.18.1/CSA B125.
PAGE 2
IV GEORGES BRASS® Installation Notes Install this product according to the installation guide. 2-1/4" (5.7 cm) 5-1/2" (14 cm) 2-1/8" (5.4 cm) 1-5/8" (4.1 cm) D. 1-1/8" D. 9/16" D. 7-3/4" (19.7 cm) 2-1/4" (5.7 cm) D. 5/8" (1.6 cm) D. 3-3/4" (9.5 cm) 2-5/8" (6.7 cm) 3-1/4" (8.3 cm) 4-1/2" (11.4 cm) 2" (5.1 cm) D. Lever 4" (10.2 cm) 1-1/4" (3.2 cm) OD 3" (7.6 cm) 2" (5.1 cm) D. Cross Product Diagram IV GEORGES BRASS® BIDET FAUCET Page 2 of 2 113777-4-BC 6-1/8" (15.
