1
Product Information
Applicable product:
Kitchen sink faucet – less handspray K-8762
Kitchen sink faucet – with accent
handspray (shown)
K-8763
Wristblade lever handles are ADA, CSA B651, OBC
compliant.
Optional accessories:
10-1/2″ (26.7 cm) escutcheon plate for
three hole installations
K-14511
Installation Notes
Install this product according to the installation guide.
Lower flow aerator options are available. Please refer to the
Kohler Price Book.
ADA, CSA B651, OBC compliant when installed to the
specific requirements of these regulations.
15-1/2"
(39.4 cm)
9-5/16"
(23.7 cm)
6-7/8"
(17.5 cm)
4-1/2"
(11.4 cm)
5" (12.7 cm)
9-1/4" (23.5 cm)
5" (12.7 cm)
11-1/8"
(28.3 cm)
1-3/4"
(4.4 cm)
Max
1-1/8" D.
3/8" OD
2-1/4"
(5.7 cm) D.
1-3/4"
(4.4 cm) D.
1-1/2"
(3.8 cm)
Max
1" D.
Roughing-In
K-8762, K-8763
ESSEX
®
KITCHEN SINK FAUCET
ESSEX
®
KITCHEN SINK FAUCET
115148-1-
CF
