Specification

KOHLER CO., Kohler, Wisconsin 53044 USA
Phone [phone], Fax [phone]
For the nearest sales and service outlet in the
US and Canada, Phone [phone]
KOHLERPower.com
Specifications
Available Options
• Wheel Kit (Ø10 by 3 inch)
• Leg Kit
• Wheelbarrow Handle Kit
• Auto-Locking Hand Truck Handle Kit
• Lifting Kit
• Extension Cord Management Kit
• Isolator Kit
© 2014 by Kohler Co. All rights reserved.
DISTRIBUTED BY:
NOTE: Dimensions are provided for reference only and should not be used for planning
installation. Contact your local distributor for more detailed information.
G3-57 (GEN5.0) 9/14
Model Name GEN5.0
Model spec
PA-GEN50-3002
PA-GEN50-2002
PA-GEN50-1001
Compliance
3002 (EPA/CARB)
2002 (EPA)
1001 (EPA/CSA)
AC rated output
(running watts)
4,300
AC maximum output
(motor starting watts)
5,000
AC voltage 120/240
AC frequency (Hz) 57.5-63
Total Harmonic
Distortion
≤ 20%
Rated VAC amperage 35.8/17.9
Max rated amperage 41.7/20.8
Engine displacement 429cc
Fuel type Gasoline
Engine RPM 3450-3750
Recommended oil SAE30
Automatic voltage
regulation
Yes
Choke location Manual on engine
Fuel shut off In tank w/filter
Starting method Recoil only
Low oil shutdown
method
Low level
Neutral Floating Neutral
Start switch type
Toggle Type
Off-On (Red)
Switch location On control panel
Fuel gauge Yes
Fuel tank capacity 8 gal/30 liters
Run time @ 50%
(hours)
20
Warranty -
Residential
3 years
Warranty -
Commercial
90 Days
Generator Set Dimensions and Weights
A mm (in.): 747 (29.4) Carton Length mm (in.): 777 (30.5)
B mm (in.): 544 (21.4) Carton Width mm (in.): 572 (22.5)
C mm (in.): 566 (22.3) Carton Height mm (in.): 599 (23.6)
D mm (in.): 1219 (48) Shipping Weight lbs (kg): 189 (86)
E mm (in.): 762 (30)
F mm (in.): 114 (4.5)
G mm (in): 140 (5.5)
Unit Weight lbs (kg): 180 (82)
