Dimensions Guide

Installation Notes
Install this product according to the installation guide.
2-1/2" (6.4 cm)
5-3/16"
(13.2 cm)
2-1/2" (6.4 cm)
5-3/16"
(13.2 cm)
3-9/16"
(9 cm)
7/8"
(2.2 cm) D.
3-3/16"
(8.1 cm)
Lever Cross
2-7/8"
(7.3 cm)
2-1/16"
(5.2 cm)
8-9/16" (21.7 cm)
7-1/16"
(17.9 cm)
8-11/16"
(22.1 cm)
Rough + Finished Deck
Mount Installation
1/4" (6 mm) to 1-1/4"
(3.2 cm) Max
Finished Deck
2-1/8" (5.4 cm) Max
Rough Deck
1-5/16"
(3.3 cm) D.
8" (20.3 cm) Min
Rim or Deck
Mount Installation
1/4" (6 mm) to
2-1/8" (5.4 cm)
Max Rim or
Deck Mount
3/4" ID
Product Diagram
MARGAUX TM
MARGAUX TM BATH FAUCET TRIM
