245
Chapter
2
9i
910
900
700
300
Pop-up Menus
in Element View
Window
Show Normal/Hide Normal
Showing or Hiding Normal Vectors
This command is used to set whether to show or hide the normal.
Operating Procedure When the Normal is Currently Hidden
1
From the pop-up menu, click [Show Normal].
The normal will be shown.
Operating Procedure When the Normal is Currently Shown
1
From the pop-up menu, click [Hide Normal].
The normal will be hidden.
Show Axis/Hide Axis
Showing or Hiding Axes
This command is used to set whether to show or hide axes.
Operating Procedure When Axes are Currently Hidden
1
From the pop-up menu, click [Show Axis].
The axes will be shown.
Operating Procedure When Axes are Currently Shown
1
From the pop-up menu, click [Hide Axis].
The axes will be hidden.
Smooth Shading/Flat Shading
Changing Shading Mode
This command is used to change shading mode.
Operating Procedure When Window is Currently in Flat Shading Mode
1
From the pop-up menu, click [Smooth
Shading].
The window will be displayed in smooth shad-
ing mode.
Operating Procedure When Window is Currently in Smooth Shading Mode
1
From the pop-up menu, click [Flat
Shading].
The window will be displayed in at shading
mode.
