User's Manual

Precautions
Location
Using the unit in the following locations can result in a malfunction.
• In direct sunlight
• Locations of extreme temperature or humidity
• Excessively dusty or dirty locations
• Locations of excessive vibration
•
Closetomagneticelds
Power supply
Please connect the designated AC adapter to an AC outlet of the cor-
rect voltage. Do not connect it to an AC outlet of voltage other than
that for which your unit is intended.
Interference with other electrical devices
Radios and televisions placed nearby may experience reception interfer-
ence. Operate this unit at a suitable distance from radios and televisions.
Handling
To avoid breakage, do not apply excessive force to the switches or
controls.
Care
If the exterior becomes dirty, wipe it with a clean, dry cloth. Do not
use liquid cleaners such as benzene or thinner, or cleaning com-
poundsorammablepolishes.
Keep this manual
After reading this manual, please keep it for later reference.
Keeping foreign matter out of your equipment
Never set any container with liquid in it near this equipment. If liquid
getsintotheequipment,itcouldcauseabreakdown,re,orelectrical
shock.
Be careful not to let metal objects get into the equipment. If something
does slip into the equipment, unplug the AC adapter from the wall
outlet. Then contact your nearest Korg dealer or the store where the
equipment was purchased.
* All product names and company names are the trademarks or reg-
istered trademarks of their respective owners.
IMPORTANT NOTICE TO CONSUMERS
This product has been manufactured according to strict specifications
and voltage requirements that are applicable in the country in which it
is intended that this product should be used. If you have purchased this
product via the internet, through mail order, and/or via a telephone sale,
you must verify that this product is intended to be used in the country
in which you reside.
WARNING: Use of this product in any country other than that for which
it is intended could be dangerous and could invalidate the manufactur-
er’s or distributor’s warranty.
Please also retain your receipt as proof of purchase otherwise your prod-
uctmaybedisqualiedfromthemanufacturer’sordistributor’swarranty.
THE FCC REGULATION WARNING (for USA)
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
theequipmentoandon,theuserisencouragedtotrytocorrectthe
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connecttheequipmentintoanoutletonacircuitdierentfrom
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
If items such as cables are included with this equipment, you must
use those included items.
Unauthorizedchangesormodicationtothissystemcanvoidthe
user’s authority to operate this equipment.
SUPPLIER’S DECLARATION OF CONFORMITY (for USA)
Responsible Party : KORG USA INC.
Address : 316 SOUTH SERVICE ROAD, MELVILLE, NY
Telephone : [phone]
Equipment Type : DIGITAL PIANO
Model : B2/B2N
This device complies with Part 15 of FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this de-
vice must accept any interference received, including interference
that may cause undesired operation.
Notice regarding disposal (EU only)
When this “crossed-out wheeled bin” symbol is displayed
ontheproduct,owner’smanual,baery,orbaerypackage,
it signifies that when you wish to dispose of this product,
manual,packageorbaeryyoumustdosoinanapproved
manner. Do not discard this product, manual, package or
baeryalongwithordinaryhouseholdwaste.Disposingin
the correct manner will prevent harm to human health and
potential damage to the environment. Since the correct method of
disposal will depend on the applicable laws and regulations in your
locality, please contact your local administrative body for details. If
thebaerycontainsheavymetalsinexcessoftheregulatedamount,
a chemical symbol is displayed below the “crossed-out wheeled bin”
symbolonthebaeryorbaerypackage.
Specications
Keyboard B2/B2SP: NH Keyboard: 88 note (A0–C8)
B2N: NT Keyboard: 88 note (A0–C8)
Maximum polyphony
120 notes /60 notes/40 notes
Sounds
12 sounds
Connectors PHONES (Headphone/Line Out), USB (TYPE B),
AUDIO IN, PEDAL
Amp output
B2/B2SP: 15 W x 2
B2N: 9 W × 2
Speakers Oval (10 cm x 5 cm) x 2
Power supply B2/B2SP: DC 15 V
B2N: DC 12 V
Power Consumption
B2/B2SP: 8 W
B2N: 6 W
Weight (excluding music stand)
B2: 11.4 kg / 25.13 lbs.
B2SP: 21 kg / 46.30 lbs.
B2N: 9.3 kg / 20.50 lbs.
Dimensions (W x D x H)
(including projections, but excluding music stand)
B2/B2N: 1312 × 336 × 117 mm/51.65 × 13.23 × 4.61"
B2SP: 1312 × 336 × 750 mm/51.65 × 13.23 × 29.53"
Included items
B2/B2N: AC adapter ( ), Music stand, Damper pedal,
Owner's Manual
B2SP: AC adapter ( ), Music stand, Stand (for use
with B2SP only) with pedal unit (supports half-
pedaling), Owner's Manual
Accessories (sold separately)
B2/B2N: Stand STB1, Pedal unit PU-2 (supports half-
pedaling)
Operating requirements (USB connection) *
Windows: Microsoft Windows 7 SP1 or later (32bit/64bit)
Mac: OS X El Capitan 10.11 or later
* Operation of the B2/B2SP/B2N is not guaranteed with all computers
that satisfy these operating requirements.
• Specificationsandappearancearesubjecttochangewithoutnotice
for improvement.
Partner mode allows you to split the keyboard into a left and right
side, and both players can play together within the same note
range. Press the power button to turn the power on while holding
down the METRONOME button. For details, download the "B2/
B2SP/B2N Partner Mode Instructions" from the Korg website
shown below.
www.korg.com
www.korg.com
Thank you for purchasing the Korg B2/B2SP/B2N Digital Piano.
Published 04/2019 Printed in China
9: Auto power-off
When 30 minutes have passed without user input or demo performance,
the instrument will be automatically turned off. To disable this function,
press “Auto power-off disable.” This will be enabled when you turn on
the power (default setting). To re-enable this function once it has been
disabled, simply turn the power of the B2/B2SP/B2N off and back on
again.
Sounds, Demo Songs and MIDI Program
Change Numbers
CC0: Bank Select (MSB) for all sounds is set to 121.
CC32 PC
Sound Song title/Composer
0 0
1 (German Concert Piano): Danse/C.Debussy
0 1
2 (Classic Piano): Waltzes Op.39-15/J.Brahms
1 0
3 (Italian Concert Piano): Je Te Veux/E.Satie
1 1
4 (Jazz Piano): I got Rhythm/G.Gershwin
2 0
5 (Ballad Piano): "Träumerei" Op.15-7/R.Schumann
0 4
6 (Stage E.Piano): Jam Session/Naoki Nishi
1 4
7 (60's E.Piano): Nighttrain/Michael Geisel
0 5
8 (Dig.E.Piano): In Memory/Michael Geisel
0 6
9 (Harpsichord) La Joyeuse/J.P.Rameau
0 19
10 (Pipe Organ) Toccata in D Minor/J.S.Bach
0 16
11 (Electric Organ) Improvisation/Michael Geisel
0 48
12 (Strings)
"Rhapsody on a Theme of Paganini" 18th Variation/
S.Rachmaninoff(arranged and played by Katsuhiro Oguri)
Troubleshooting
If you perceive any unexpected behavior from your Korg B2/B2SP/B2N
Digital Piano, please see if this guide addresses your concern. If not, or if
the problem persists, contact your nearest Korg distributor.
The Instrument turns off
If the power is left on for 30 minutes or more without the keyboard
being played, the auto power-off function will turn off the B2/B2SP/B2N
automatically. To use the B2/B2SP/B2N, press the power button again to
turn it on.
The Sound is interrupted
The instrument sounds in the B2/B2SP/B2N are created by recording
individual samples made from the actual instruments, processing them,
and combining them to achieve the desired sound. Depending on the
detail and complexity of the sound, one, two, or even three samples may
be combined to create each note. Nearly all of the sounds on the B2/
B2SP/B2N use two samples per note played. Due to this, the maximum
polyphony or number of notes that can sound at once (including when
the damper pedal is pressed) is 60. (Note that the Italian concert piano,
jazz piano and ballad piano sounds use three samples per note, which
brings the maximum polyphony down to 40.) However, the stage electric
piano sound has a maximum polyphony of 120 notes.
The pitch or tone of the piano sounds incorrect in some key regions
The B2/B2SP/B2N’s piano sounds replicate the sound of an actual piano
as faithfully as possible. This means that in some regions of the keyboard,
you may sense that the overtones seem stronger, or that the tone or pitch
seems wrong. This reflects the acoustic nature of the original instrument
being sampled, and is not a malfunction.
