Connections
> Connecting to external audio devices
9
Connecting to external audio devices
Connecting to an external amplification system
Use the OUTPUT connectors, if you like to connect your C-
720 to a high-quality mixer, stereo hi-fi, or a couple of active
monitors. When using a stereo hi-fi, connect the OUTPUTs to
the LINE, AUX, CD or TAPE inputs (never use the PHONO
inputs). For mono amplification, connect only the L/MONO
output.
Connecting other audio devices to the C-720
Use the INPUT connectors, to connect a computer, mixer,
drum machine, synthesizer, MP3 or tape player, to your C-
720, and hear their sound run through its speakers. For mono
amplification, connect only the L/MONO output.
Do not con-
nect the output of a power amplifier!
L/MONO
R
AUX IN
INPUT
OUTPUT
