Basic functions > Playing two sounds at the same time (Layer mode)
14
Playing two sounds at the same time (Layer mode)
You can play two sounds at the same time on the keyboard. It
is like having two “overlapping” sounds. This is called the Lay-
er mode.
Keep in mind that, when in Layer mode, the total number of
voices that you can play at the same time is reduced, depend-
ing on the total number of oscillators used by the selected
sounds.
Entering the Layer mode
To access Layer mode from any other mode, press together
two sound selection buttons. The lowest-numbered sound in
the following diagram will be the Main sound, while the high-
est-numbered sound will be the Layer sound:
The name of the two sounds will appear in the display:
Exit from the Layer mode
To exit Layer mode, press a single sound selection button, or
the SPLIT button. You will return to the Single mode, with a
single sound playing on the keyboard, or to the Split mode,
with a sound on the left and one on the right of the split point.
Selecting a different pair of sounds
To select different sounds, press a different pair of sound selec-
tion buttons. The last selected variation of the sounds corre-
sponding to the new buttons will be selected.
Selecting a variation of the Main sound
You can select a variation of the current Main sound.
1. Be sure the cursor is in the first line of the display. If it isn’t,
use the SCROLL
button to move it there:
2. Use the VARIATION button to select a different sound
variation. As an alternative, use the +/YES and -/NO but-
tons to choose a different sound variation.
Selecting a variation of the Layer sound
You can select a variation of the current Layer sound.
1. Use the SCROLL
button to move the cursor to the Lay-
er sound.
2. Use the VARIATION button to select a different sound
variation. As an alternative, use the +/YES and -/NO but-
tons to choose a different sound variation.
3. If you desire so, use the SCROLL
buttons to move the
cursor back to the Main sound.
Balancing layered sounds
You can adjust the sound’s volume balance.
• Keep the Main sound button pressed, to increase its vol-
ume and (after the maximum value has been reached)
decrease the volume of the Layer sound. Release the but-
ton when done.
• Keep the Layer sound button pressed, to increase its vol-
ume and (after the maximum value has been reached)
decrease the volume of the Main sound. Release the but-
ton when done.
While the volume is changing, a meter is shown in the display:
Layer
Main
12345
678910
GrandPiano 4/4
Strings 120
Main sound
Layer sound
GrandPiano 4/4
Strings 120
Cursor
GrandPiano 4/4
Strings 120
GrandPiano 4/4
Strings 120
Scroll
M:90
L:127
Main sound’s volume
Layer sound’s volume
