The metronome > Adjusting the metronome level
22
Adjusting the metronome level
You can adjust the metronome’s level, in relation to the overall
instrument’s volume.
1. Press the TEMPO/MET.SET buttons together. The first
Metronome page should appear.
2. Press the SCROLL
button to go to the second Metro-
nome page, Metro Lev/Rev. The Lv (Level) parameter will
be selected:
3. Use the +/YES and -/NO buttons to change the metro-
nome’s volume.
4. Press the EXIT button to return to the Main page.
Adjusting the drum pattern’s reverb
You can add a reverb effect to the drum patterns.
Note: Reverb does not apply to the metronome click (i.e., when
an ordinary time signatures is chosen).
1. Press the TEMPO/MET.SET buttons together.
2. If you are not there, use the SCROLL
/
buttons to se-
lect the Rv (Reverb) parameter:
3. Use the +/YES and -/NO buttons to change the metro-
nome’s reverb.
4. Press the EXIT button to return to the Main page.
Selecting the accent
The accented beat of the ordinary times signatures can be
changed to a marcato or bell sound.
Note: The accent does not apply to drum patterns.
1. Press the TEMPO/MET.SET buttons together.
2. If you are not there, use the SCROLL
/
buttons to go
to the Metro Accent page:
3. Use the +/YES and -/NO buttons to turn the bell on or off,
and choose one of the available accent options.
4. Press the EXIT button to return to the Main page.
Saving the metronome settings
Metronome settings can be saved, so that they are not reset to
the default values when turning the instrument off. This pro-
cedure saves time signature, volume setting, reverb setting, ac-
cent. On the contrary, tempo settings are always reset.
1. Press the TEMPO/MET.SET buttons together. The first
Metronome page appears.
2. Press the SCROLL
button four times, to go to the
fourth Metronome page. The Metro Settings Save param-
eter will be selected:
3. Press +/YES to confirm saving, or -/NO to cancel saving.
You are automatically kept back to the Main page.
Metro Lev/Rev 2
Lv:100 Rv:64
Metro Lev/Rev 2
Lv:100
Rv:64
Metro Accent 3
Bell
Option Meaning
Off No accent
Marcato The first beat is played louder
Bell The first beat is played by a bell sound
Metro Settings 4
Save? (Yes/No)
