Editing sounds and performances > Setting the octave transposition
43
Press the SCROLL
button to go to the IFX Wet/Dry
edit page, with the M (Main) parameter selected:
Use the +/YES and -/NO buttons to set the amount of IFX
applied to the Main sound.
This is the diagram of the mix betweeen Wet and Dry set-
tings:
3. If you are in Layer or Split mode, press SCROLL
again
to select the L (Layer/Left) parameter:
Use the +/YES and -/NO buttons to set the amount of IFX
applied to the Layer/Left sound.
4. Press the EXIT button to return to the Main page and save
the changes (see “Exit from the Sound edit mode” on
page 38), or the SCROLL
button to go to the next edit
page (see below).
Setting the octave transposition
Here you can set the individual octave transposition for the
Main and the Layer/Left sounds.
1. After having pressed the EDIT button, use the SCROLL
button to go to the Octave edit page, with the M (Main)
parameter selected:
Use the +/YES and -/NO buttons to change the octave
transposition, within a range of ±4 octaves.
2. If you are in Layer or Split mode, press SCROLL
again
to select the L (Layer/Left) parameter:
Use the +/YES and -/NO buttons to change the octave
transposition.
3. Press the EXIT button to return to the Main page and save
the changes (see “Exit from the Sound edit mode” on
page 38), or the SCROLL
button to go to the next edit
page (see below).
Value Meaning
–Wet Wet, i.e., maximum effect applied. Negative
(inverted) phase.
W-99 ~ W-51 Mostly wet, with negative value.
D-50 ~ D-01 Mostly dry, i.e., minimum effect applied. Nega-
tive (inverted) phase.
Dry Dry, i.e., with no effect at all.
D001 ~ D050 Mostly dry, i.e., minimum effect applied.
W051 ~ W099 Mostly wet.
Wet Wet, i.e., maximum effect applied.
IFX Wet/Dry 8
M:W099 L:D020
Wet
Dry
100%
Wet
100%
Dry
100%
0%
IFX Wet/Dry 8
M:W099
L:D020
Value Meaning
-04 ~ -01 Four to one octave lower
+00 No transposition
+01 ~ +04 One to four octave higher
Octave 9
M:+02 L:+00
Octave 9
M:+02
L:+00
