Global settings > Touch settings
47
Global settings
Global edit is where you can edit some general parameters, not
tied to the single sounds or songs.
Accessing Global edit
Keep the EDIT button pressed for more than one second, to
access the Global edit mode.
Exit from the Global edit mode
After having edited some parameter, press EXIT to exit the
Global mode. If nothing was modified, you exit immediately.
If something was modified, the Save page will appear:
Press +/YES to save, -/NO to cancel.
Touch settings
The keyboard sensitivity, or touch, can be programmed.
1. After having kept the EDIT button pressed, use the
SCROLL
button to show the Touch Sensitivity page:
2. Use the +/YES and -/NO button to change sensitivity. The
following table lists the available touch settings.
This is the diagram of the touch curves:
3. Press the EXIT button to return to the Main or Song Play
page and save the changes (see “Exit from the Global edit
mode” on page 47), or the SCROLL
button to go to the
next edit page (see below).
Turning the internal speakers on or off
Whether you prefer listening to the internal speakers or to an
external amplification system, you can turn the internal speak-
ers on or off.
Note: The speakers are automatically turned on when the in-
strument is turned on again.
Hint: You can also turn the speaker off, by inserting a jack in
the headphone connectors.
1. After having kept the EDIT button pressed, use the
SCROLL
button to show the Speaker page:
2. Use the +/YES and -/NO button to turn the internal speak-
ers on or off.
3. Press the EXIT button to return to the Main or Song Play
page, or the SCROLL
button to go to the next edit page
(see below).
Global Modified
Save? (Yes/No)
Setting Touch sensitivity
Fixed Fixed dynamic = 100.
Soft 1~3 Loud notes can be produced even by playing
lightly.
Medium 1~2 Normal piano touch.
Hard 1~3 Loud notes can be produced only by playing
very hard.
Touch Sens. 1
Medium 2
Playing strength
Soft
Soft
()
Strong
Strong
( )
Note
loudness
Soft
Hard
Medium
Speaker 2
On
