Assembling the stand > Assembling procedure
62
Assembling procedure
1. Open the packing carton and take out the contents. Check
that all of the following items are available.
NB: You will need a cross-point (Phillips #2) screwdriver
for assembly.
2. With the finished surface (woodgrain) facing forward to-
ward the pedals, attach the pedal beam (A) to the front bar
(B), by inserting the four bolts on the front of the pedal
beam (A) into the corresponding holes in the front bar (B).
Fasten the two pieces using two screws (a).
14 x a
5 x b
2 x e
4 x c
10 x d
A
B
C
D
E
F
G
List of parts
A Pedal “beam” × 1
B Front bar × 1
C Left side panel × 1
D Right side panel × 1
E Speaker box × 1
F C-720 × 1
G Rear panel × 1
a Screws M4x10 TC × 14
b Screws M4x20 TC × 5
c Screws M6x20 TBL × 4
d Screws 4x15 TFR × 10
e Protective cardboard sheets × 2
a
a
A
B
C720_English.fm Page 62 Tuesday, October 10, 2006 4:14 PM
