Appendix > Performances
70
Performances
# Btn Name Sounds / Timbres Mode Remarks
Bank 1
1 1 Split&Layr Piano&Str., Ac. Bass Split
2 2 Grand&Ride GrandPiano, Bass&Ride Split
3 3 Grand&Ebas GrandPiano, El. Bass Split
4 4 PnoStrings GrandPiano, String Pad Layer
5 5 EGrand Pad Elec.Grand, String Pad Layer
6 6 Piano Pad Piano&Pad, String Pad Layer
7 7 Pno Choirs GrandPiano, Vocal Pad Layer
8 8 Pno Guitar Piano&Str., Nylon Gtr. Layer
9 9 Piano BX3 BriteGrand, Perc.Org.2 Layer
10 10 DualManual Perc.Org.2, Jazz Organ Layer
Bank 2
11 1 Digital EP GrandPiano, Dig. EP 1 Layer
12 2 PaddedTine Tine EP 1, Vocal Pad Layer
13 3 R&B EPno DynoTineEP, TremReedEP Layer
14 4 EP Choir Tine EP 1, Vocal Pad Layer
15 5 EP&NoFret Tine EP 2, Fretless B Split
16 6 Scat&Bass ScatVoices, Bass&Ride Split
17 7 Vibes&Bass Vibes 1, Bass&Ride Split
18 8 Bass&Guitr Nylon Gtr., Ac. Bass Split
19 9 Org&Bass 1 Perc.Org.1, Ac. Bass Split
20 10 Org&Bass 2 Jazz Organ, Ac. Bass Split
Bank 3
21 1 Baroque Harpsi 8, Strings Layer
22 2 Harpsi-Ch Harpsi 8, Choir Layer
23 3 Harpsi-Org Harpsi 8, Pipe Tutti Layer
24 4 Church Mix Church Org, Choir Layer
25 5 Guitar Pad Nylon Gtr., Slow Str. Layer
26 6 GrandPiano GrandPiano Single Stereo sound. No EPx for increased polyphony
27 7 BriteGrand BriteGrand Single
28 8 MelloGrand MelloGrand Single
29 9 2 Pianists GrandPiano, GrandPiano Split The same piano sound is assigned to the two halves of the keyboard,
simulating two separate pianos on the same keyboard. Useful when
both the teacher and student are playing on the piano at the same
time.
30 10 PnoEXpDEMO** GrandPiano Single GrandPiano demo with enhanced PnoExp effects
Legend:
Btn: Button. Bank: Select it with the VARIATION button.
Notes:
* These performances, with sounds set in Layer mode, do not use EPx effects.
** Performance 30 (PnoExpDEMO) is designed to demonstrate our “Piano eXperience” technology, by exaggerating the amount of key-off/
hammer return portion of the Grand Piano sound; it is not intended to be a play-able timbre. Normally, these additional Piano eXperience
sounds are not perceived as separate elements, but together with the other sample layers, they are a vital part of the realism and the
authentic piano tone.
