Electronic Keyboard User Manual

MIDI Implementation Chart > Polyphony
77
MIDI Implementation Chart
Function Transmitted Recognized Remarks
Basic Channel Default 1–16 1–16 Memorized
Changed 1–16 1–16
Mode Default 3
Messages X X
Altered ****************
Note
Number:
0–127 0–127 0 – 120 in the case of piano sounds
True Voice **************** 0–127
Velocity Note On O 9n, V=1–127 O 9n, V=1–127
Note Off X V=64 X
Aftertouch Poly (Key) O O Recorded though the Global channel *1
Mono (Channel) O O *1
Pitch Bend O O *1
Control
Change
0, 32 O O Bank Select (MSB, LSB) *2
1, 2 O O Modulations *1, 2
6 O O Data Entry MSB *1, 2
38 O O Data Entry LSB *2
7 O O Volume *2
11 O O Expression *1, 2
10, 91, 93 O O Panpot, Reverb Send, Chorus Send *2
64, 66, 67 O O Damper, Sostenuto, Soft *2
65, 5 O O Portamento On/Off, Portamento Time *1, 2
71, 72, 73 O O Resonance, EG time (Release, Attack) *1, 2, 3
74 O O Brightness *2, 3
75, 76, 77, 78 O O Decay Time, Vibrato Rate, Depth, Delay *1, 2, 3
98, 99 O O NRPN (LSB, MSB) *1, 2
100, 101 O O RPN (LSB, MSB) *1, 2, 4
120, 121 X O All sounds off, Reset all controllers *2
Program
Change
O O Transmitted/recognized numbers: *2
0-7, 11, 16, 17, 19, 20, 24, 32, 33, 35, 48-50, 52-54
True # **************** 0–127
System Exclusive O O *5
System
Common
Song Position X X
Song Select X X
Tune X X
System
Real Time
Clock O O
Commands O O
Aux
Messages
Local On/Off X O
All Notes Off X O (123–127)
Active Sense O O
Reset X X
Notes *1: Only recorder data are transmitted.
*2: Sent and received when MIDI Filter is set to Off in Global mode.
*3: Received, but not recorded by the onboard Recorder.
*4: LSB, MSB = 01,00: Fine Tune.
*5: Includes Inquiry and GM Mode On.
Mode 1:OMNI ON, POLY
Mode 3:OMNI OFF, POLY
Mode 2:OMNI ON, MONO
Mode 4:OMNI OFF, MONO
O: Yes
X: No
KORG C-720
Version 1.0 - Jul. 16, 2006
C720_English.fm Page 77 Tuesday, October 10, 2006 4:14 PM
