Portable CD Player User's Manual

SWITCHING THE UNIT ON/OFF
Switch on the unit by pressing any button
(except OPEN button (7) and button
(4)). When system is on, press POWER
button (9) to turn off the unit.
FACEPLATE RELEASE
Press OPEN button (7) to detach the
removable faceplate.
SOUND ADJUSTMENT
Press and release SEL button (10) to
select the desired adjustment mode.
The adjustment mode will change in the
following order:
By rotating the VOLUME knob (11)
clockwise or counter-clockwise, it is
possible to adjust the desired sound quality.
Press and hold the SEL button (10) for
several seconds to enter into the selection
mode for the choice of beep sound, then
rotate VOLUME knob (11) to select as
follows:
BEEP 2ND BEEP ALL BEEP OFF
- BEEP 2ND mode:
The beep is only generated when
buttons performing double functions
are pressed for several seconds.
e.g.
When preset button is pressed.
When BND/LOU button (13) is
pressed.
When AMS button (18) is pressed.
- BEEP ALL mode:
The beep is generated when every
button is pressed.
- BEEP OFF mode:
The beep is disabled.
LOUDNESS
Press BND/LOU button (13) for several
seconds to reinforce the bass output.
Press it for several seconds again to
release this function.
SET THE CLOCK
Press the DSP button (15), the clock is
displayed on the LCD display. Then hold
down the button until the clock flashes.
Then press the TUNE/TRACK
button
(17) to change hours or TUNE/TRACK
button (16) to change minutes.
10
OPERATION
MUTE
Press MUT button (3) to mute the volume
instantly. If any button is pressed while
in the mute mode, the mute function is
released.
EQUALIZATION
Press EQ button (19) to turn on
equalization function and to select
desired audio mode. There are four kinds
of mode as below:
LIQUID CRYSTAL DISPLAY
Shows current frequency and activated
functions on the display (8).
REMOTE SENSOR
Point the remote cantrol handset to the
remote sensor IR (24). Press the function
keys on the handset to control the
system.
RESET FUNCTION
RESET
button (12) must be activated
with either a ballpoint pen or thin metal
object.
The RESET button is to be activated for
the following reasons:
- Initial installation of the unit when all
wiring is completed.
- All the function buttons do not operate.
- Error symbol on the display.
Note: If you press RESET button (12),
the unit still does not work, please use a
cotton swab soaked in isopropyl alcohol
to clean the socket on the back of the
front panel.
RADIO OPERATION
• SWITCHING TO RADIO MODE
Press MOD button (6) to select radio
mode, the radio mode appears in the
display together with the memory band
and frequency.
VOL BAS TRB BAL FAD
(Volume) (Bass) (Treble) (Balance) (Fader)
FLAT CLASSICS POP M ROCK M DSP OFF
