User manual

Your HDMI/RS-232/IR Line Transmitter / Receiver
5
• Supports standard, enhanced, high-definition video, and multi-channel
digital audio
1
on a single cable
• Transmits all ATSC HDTV standards and supports 8-channel digital
audio, with bandwidth to spare to accommodate future enhancements
and requirements
• Benefits consumers by providing superior, uncompressed digital video
quality via a single cable
2
, and user-friendly connector
• Is backward-compatible with DVI (Digital Visual Interface)
• Supports two-way communication between the video source (such as a
DVD player) and the digital television, enabling new functionality such
as automatic configuration and one-button play
HDMI has the capacity to support:
• Existing high-definition video formats (720p, 1080i, and 1080p/60), as
well as standard definition formats such as NTSC or PAL
3.5 Recommendations for Achieving the Best Performance
To ac
hieve the best performance:
• Connect only good quality connection STP CAT 5 24 AWG cables,
thus avoiding interference, deterioration in signal quality due to poor
matching, and elevated noise-levels (often associated with low quality
cables)
• Avoid interference from neighboring electrical appliances and position
your TP-573/TP-574 away from moisture, excessive sunlight and dust
4 Your HDMI/RS-232/IR Line Transmitter / Receiver
This section describes the:
• TP-573 HDMI/RS-232/IR Line Transmitter, see section 4.1
• TP-574 HDMI/RS-232/IR Line Receiver, see section 4.2
1 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to
support Dolby 5.1 audio and high-resolution audio formats
2 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a
simple, cost-effective manner
