1 Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis.
2 Getting Started We recommend that you: • Unpack the equipment carefully and save the original box and packaging materials for possible future shipment • Review the contents of this user manual Use Kramer high performance high resolution cables 2.
3 Overview The KramerTOOLS 4x1V and 4x1VB are high-quality 4x1 mechanical switchers designed for composite video signals using RCA or BNC connectors. They accept up to four inputs and let you select any input to be routed to one output using buttons located on the front panel. High-quality switching components ensure minimal crosstalk and a high bandwidth of 400MHz (-3dB). The entirely passive design of the 4x1V and 4x1VB eliminates the need for a power supply.
Figure 1: 4x1V and 4x1VB 4:1 Video Switchers # 4 Feature Function 1 OUTPUT Connector Connect to the composite video acceptor RCA connector (4x1V), BNC connector (4x1VB) 2 IN 1 to IN 4 Connectors Connect to the composite video sources (1 to 4) RCA connectors (4x1V), BNC connectors (4x1VB) 3 INPUT SELECTOR Buttons Buttons for choosing the input CV source 4x1V and 4x1VB - Overview
4 Connecting and Operating the 4x1V and 4x1VB To connect the 4x1V and 4x1VB as illustrated in the example in Figure 2: 1. Connect up to four composite video sources to the IN 1 to IN 4 connectors (for example, composite video players). You do not have to connect all inputs. 2. Connect the OUTPUT connector to a composite video acceptor (for example, a composite video recorder). i Note: The 4x1V uses RCA connectors. The 4x1VB uses BNC connectors.
Figure 2: Connecting the 4x1V and 4x1VB 4:1 Video Switchers 6 4x1V and 4x1VB - Connecting and Operating the 4x1V and 4x1VB
5 Technical Specifications INPUTS: 4 video, 1Vpp/75Ω on RCA connectors (4x1V) or BNC connectors (4x1VB) OUTPUT: 1 composite or single component video, 1Vpp/75Ω on an RCA connector (4x1V) or BNC connector (4x1VB) BANDWIDTH (-3dB): 400MHz SWITCHING SYSTEM: Mechanical, break-before-make OPERATING TEMPERATURE: 0° to +55°C (32° to 131°F) STORAGE TEMPERATURE: -45° to +72°C (-49° to 162°F) HUMIDITY: 10% to 90%, RHL non-condensing DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.9" x 1") WEIGHT: 0.
