C-5BM/5BM

5 BNC RGBHV Mini Coax Cable

| 3G HD-SDI - BNC

Kramer’s C-5BM/5BM is constructed of 5 mini coax

cables in a single jacket with 75 BNC connectors at

each end. It offers outstanding quality, durability, and

high performance for any RGBHV video signal

application

FEATURES

Quality Construction - Constructed from flexible, high quality 5 mini coax cable

Applications - Ideal for routing typical computer graphics video RGBHV signals to display devices

such as projectors and monitors

Easy Installation - Breakout length is 18in (0.5m) on any cables 6ft (1.8m) or longer. Shorter cables

have approx. 7in (0.18m) breakout length

Varied Selection of Lengths - Available in versions of 3 to 100ft (0.9 to 30.5m)

Cable Specs - For detailed cable specs, see Kramer BC5X

PAGE 1
C-5BM/5BM 5 BNC RGBHV Mini Coax Cable | 3G HD-SDI - BNC Kramer’s C-5BM/5BM is constructed of 5 mini coax cables in a single jacket with 75 BNC connectors at each end.
PAGE 2
TECHNICAL SPECIFICATIONS CONSTRUCTION Coax Center Conductor: 28 AWG 7/36 tinned copper Dielectric: Foam polyethylene Shield: 90% braid 38 AWG tinned copper Coax Jacket Colors: Red, green, blue, yellow, black Outer Jacket: PVC Outer Jacket Color: Dark gray with white lettering DIAMETERS Center Conductor: 0.38mm (0.015in) Individual Coax: 2.75mm (0.108in) Outside Diameter: 9.2mm (0.362in) Dielectric: 1.6mm (0.063in) ELECTRICAL Impedance: 75 DC Resistance: 237/km (72.2/1000ft) Capacitance: 60pF/m (18.
PAGE 3
CONFIGURATIONS C-5BM/5BM-3 5 BNC (M) to 5 BNC (M) Cable C-5BM/5BM-10 5 BNC (M) to 5 BNC (M) Cable C-5BM/5BM-15 5 BNC (M) to 5 BNC (M) Cable C-5BM/5BM-25 5 BNC (M) to 5 BNC (M) Cable C-5BM/5BM-35 5 BNC (M) to 5 BNC (M) Cable C-5BM/5BM-50 5 BNC (M) to 5 BNC (M) Cable C-5BM/5BM-75 5 BNC (M) to 5 BNC (M) Cable C-5BM/5BM-100 5 BNC (M) to 5 BNC (M) Cable
