I N S TA L L AT I O N MA N UA L Zero-Radius Handmade Stainless Steel Kitchen Sinks (Pax™ and R0 PRO™ Series) KHU15 & KHU15C / KHU19 & KHU19C / KHU23 & KHU23C / KHU24L & KHU24CL / KHU29 & KHU29C KHU32 & KHU32C / KHU322 & KHU322C www.kraususa.com I toll free: 1.800.775.0703 I © 2014-2015 Kraus USA Inc. I REV.
Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help. For more information about Kraus products, please visit: www.kraususa.
Prior to Installation: • Make sure that you have all necessary parts by checking the parts list.
Phillips screwd Silicone Sealant Safety Goggles Drill Phillips Screwdriver Putty Knife Silicone Sealant Silicone Adhesive Jig Saw Adjustable wrench Tape Measure Pencil Phillips screwdriver Tools You Will Need Scissors Screwdriver NOTE: Specialized tools may be necessary to install Kraus Stainless Steel Undermount sinks with countertop materials other than wood, marble, or granite D Parts List • Cut-Out Template • Mounting Hardware • Bottom Grids • Drain • Compatible with Kraus Exclusive g
17" 18-1/2" 17" 18-1/2" Dimensions 17" 18-1/2" 10" 10" 13" 14-1/2" 95° 95° 17" 18-1/2" 17" 18-1/2" KHU19 & KHU19C 18.5” x 18.5” x 10” Min Cabinet Size: 24” Drain Model #: ST-3 Optional Drain#: GDA-1 KHU15 & KHU15C 14.5” x 18.5” x 10” Min Cabinet Size: 18” Drain Model #: ST-3 Optional Drain#: GDA-1 22-1/2" 21" 10" 12" 24" 22-1/2" 95° 95° KHU23 & KHU23C 22.5” x 18.5” 10” Min Cabinet Size: 27” Matching Grid: KBG-H23 Drain Model #: ST-3 Optional Drain#: GDA-1 KHU24L & KHU24CL 24” x 18.
17" 10" 10" 30" 31-1/2" 95° 95° KHU32 & KHU32C 31.5” x 18.5” x 10” Min Cabinet Size: 36” Matching Grid: KBG-H32 Drain Model #: ST-3 Optional Drain#: GDA-1 17" 14-1/2" 18-1/2" KHU29 & KHU29C 28.5” x 18.5” x 10” Min Cabinet Size: 33” Matching Grid: KBG-H29 Drain Model #: ST-3 Optional Drain#: GDA-1 14-1/2" 10" 31-1/2" 95° 95° KHU322 & KHU322C 31.5” x 18.
DETERMINE REVEAL TYPE 1.
Step1 2.
Step2 3.
Step3 FLUSHED/ZERO Centerline 4.
Determine location for mounting brackets; space 3/8”POSITIVE 5. Set up Mounting Brackets 1/8”NEGATIVE FLUSHED/ZERO kets; space 2" mm) • Turn countertop over and align sink with countertop. Decide location for mounting brackets • Mounting holes should be ½” from edge of sink Centerline Step5 Step6 1/2" (13mm) Step5 6.
7. Install Anchors Step6 • Insert anchors into drilled holes and lightly tap with a hammer until flush 1/2 Step7 8. Secure Sink to Countertop • Use a bead of silicone (or preferred adhesive) around the rim of the sink. Check the alignment of the sink to the cutout in the countertop.
9. Attach Mounting Hardware Step8 • Attach mounting hardware to secure bowl.
Step9 10. Install Plumbing Fixtures • Connect drain to sink. Connect trap to drain.
Codes/Standards Applicable: HELP LINE Our customer service hours are Monday – Friday, 9am – 8pm EST. Be sure to visit our website at www.kraususa.com If you are a HOMEOWNER please contact a Kraus Customer Service Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a PLUMBING CONTRACTOR OR TRADE PROFESSIONAL please contact a Kraus Pro Representative at: Kraus USA, Inc.
R E G I S T E R Y O U R P R O D U C T T O D AY Receive Proof of Ownership Access Customer Care & Installation Help Get Exclusive Kraus Offers & Promotions Scan to Register Online or visit http://www.kraususa.com/registration We’re always looking for ways to improve. Please take a moment to share your experience. Visit http://www.kraususa.com/review to let us know what you think about your new Kraus product. Contact Us to Learn More 1.800.775.0703 / www.kraususa.com / customerservice@kraususa.
