I N S TA L L AT I O N MA N UA L Single Lever Pull-Out Kitchen Faucet KPF-1621 www.kraususa.com I toll free: 1.800.775.0703 I © 2013-2014 Kraus USA Inc.
Congratulations on your new Kraus purchase! We would like to take this opportunity to thank you for your business with Kraus USA. It is our sincere hope that you are completely satisfied with your Kraus experience. We welcome any questions or comments you may have, and look forward to assisting you in the future. For more information about Kraus products, please visit our website at: www.kraususa.com. In order to allow us to serve you better, we recommend registering your new Kraus product at: www.kraususa.
Prior to Installation • • • • Make sure that cold and hot water lines are turned off Wrap all threaded connections with Teflon tape. Always wrap in a clockwise direction Cover your drain to avoid losing parts Do not disassemble the main faucet body, as it has been installed & commissioned correctly & precisely before delivery from the factory • To keep the faucet from jamming, flush the water pipe before installation • Using condition: Working pressure at 0.05-1.
KPF-1621 Diagram and Parts List 9 Included Parts: 8 1 11 10 10 11 9 0 9 1 14 2 3 7 15 12 2 3 4 12 5 6 13 7 10 1. Faucet Body 2. Base O-Ring 3. Rubber Washer 4. Metal Washer 5. Mounting Nut 6. Mounting Screws (2) 7. Weight 8. Spray Head 9. Spray Hose 10. Hot and Cold Waterlines (2) 11.
Dimension Drawings 249 11 9/16” 20° 231 9 3/32” Ø35~Ø38 Ø3/8”~Ø1 1/2” Hot Water Cold Water Safety Tips • If soldering the water connections when installing the faucet, remove the O-rings, cartridges, and washers before applying any heat • Protect your eyes with safety glasses when cutting or soldering
475 18 3/4” Dimension Drawings ot ater Max35 Max1 3/8” ” Cold Water Safety Tips • Do not overtighten fixing screws/nuts.
Faucet Installation Methods Installation Method 1 md imu ” 3.5 The minimumandistance between the th s s faucet hole Le and the wall should be 3.5” 30˚ Min .5” 3 ce n ista Installation Method 2 an s th ” If the distance between the faucet hole 3.5 and the wall is less than 3.
2 3 4 5 6 Faucet Installation Steps 1 Step 1 8 ~Ø3 Ø35 1/2” ~Ø1 ” 8 / 13 Ø 1 8 ~Ø3 Ø35 ” 1 1/2 ”~Ø 8 / 3 1 Ø Step 2 2 Remove mounting screws (6), 3 mounting nut (5), metal washer 4 (4), and rubber5washer (3) from the faucet body (1)6 2 3 4 5 6 1 1 9 9 8 8 1 2 9 8 2 2 3 4 5 6 3 4 5 6 Connect spray head (8) to spray hose (9) and tighten firmly.
Step 3 After adjusting the direction of the faucet body(1), tighten the mounting nut (5) until snug and tighten the mounting screws (6) to the nut with a Philips head screwdriver 5 6 Hot Water Step 4 7 Connect the spray hose (9) to the supply line and tighten with a wrench until snug, then install the weight (7) at the lowest point (horizontally) on the spray hose (9) join hose Hot Cold Water Water 7
Step 5 Connect hot and cold waterlines (10) to the angle stops and tighten with a wrench until snug, then unscrew spray head (8), hold the tip of the spray hose (9) and turn on the faucet to flush any debris
Usage How to Operate the Handle join hose Hot Cold Water Water 1. Pull the lever to the right 7 to turn on the water. Push to the left to turn off 2.
Close 25˚ 90˚ Care & Maintenance Push *To keep the product clean & shining, follow the steps below: Open 1. 2. 3. 4.
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM CAUSE ACTION Leakage under the handle Locking nut has come loose Remove the index button at the top of the handle. Loosen set screw with a hex wrench. Remove the handle and unscrew trim cap by hand.
Codes/Standards Applicable: Specified model meets or exceeds the following: ANSI/ASME A112.18.1, cUPC, AB1953 KRAUS LIMITED LIFETIME WARRANTY This product has been manufactured and tested to the highest quality standards by Kraus USA Inc. (“Kraus”). We offer our customers thoughtfully crafted fixtures & accessories, engineered for enduring performance over years of use. WHO IS COVERED BY THE WARRANTY This warranty extends to the original purchaser only.
C. Kraus recommends installing all Kraus products with a licensed, professional plumber. Kraus will not be held responsible for any damage or product failure due to improper installation, misuse, or failure to use a licensed professional. Please read your care and maintenance documentation to determine the limits of proper use. D. Commercial use will automatically void this warranty. E. This warranty is not applicable to Kraus products purchased from an unauthorized seller.
