Installation Guide

Dimension Drawings
249
11 9/16”
20°
231
Ø35~Ø38
Ø3/8”~Ø1 1/2”
Hot
Water
Cold
Water
475
18 3/4”
Max35
Max1 3/8”
9 3/32”
Safety Tips
•
If soldering the water connections when installing the faucet, remove the O-rings,
cartridges, and washers before applying any heat
• Protect your eyes with safety glasses when cutting or soldering
