I N S TA L L AT I O N MA N UA L Oletto™ Single Lever Pull Down Kitchen Faucet KPF-2620 www.kraususa.com I toll free: 1.800.775.0703 I © 2014-2015 Kraus USA Inc. I REV.
Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help. For more information about Kraus products, please visit: www.kraususa.
7/8” (22mm) 19.7 º Prior to Installation: • 10 1/8” 8 5/16” Make(257mm) sure you have all necessary (21mm) parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800- ∅ 1 15/16” 775-0703 for a replacement (∅ 50mm) ∅ 1 3/4” • (∅ 45mm) ∅ 1 15/16” (∅ 50mm) • 1 3/8” (35mm) Turn off the hot and cold water supply at the angle stops and turn on the old faucet to release any built up pressure. Remove existing faucet.
Diagram and Parts List A. Spray Head B. Faucet Body C. Deck & Putty Plate B D. Base A D E. Spray Hose F. Supply Hose G. Hot & Cold Waterlines J C H. Weight I. Quick Connect J. Hex Wrench Set J1. 2.5mm J2.
Faucet Dimensions 10-1/2” (267mm) 10-1/4” (260mm) 15-3/4” (400mm) 8-3/4 (221mm) 4-1/4” (109mm) 8-1/4” (208mm) 7-1/4” (186mm) 15º 24-1/2” (620mm) 1-5/8” (40mm) 1/16”~1-1/8” (1mm~30mm) 2-1/2” (62mm) Check Value 9/16-24 UNEF (3/8” Compression) 4
Step 1A: Install base without deck & putty plate 1A 1B Insert base (D) into sink or countertop with “FR↑NT” facing forward.
Step 1B: Install base with deck & putty plate 1B Place a bead of clear silicone sealant (not included) around the edge of the putty plate (C). Secure 2 deck & putty plate (C) on sink or countertop. Insert base (D) into hole of deck & putty plate (C) with “FR↑NT” facing forward.
Step 2: Install faucet G G G Remove Quick Connect (I) from spray hose (E). Insert spray hose (E) into small hole of base (D). Insert hot & cold waterlines and supply hose (F), one by one, in large hole of base B E G F F D D Step 3: Secure faucet Align arrow on faucet body (B) with arrow on base (D). Attach faucet body (B) to base (D) and turn counter-clockwise. Secure faucet body (B) by tightening the set screw with 2.
G G Step 4: Connect waterlines to main valve B E G G F F D Installer Tip: Use two wrenches when securing waterlines to angle stops to prevent kinking, as shown in picture G G Hot Thread hot & cold waterlines (G) onto angle stops. Tighten with adjustable wrench until snug.
G G Cold Hot Step 6: Install weight Attach weight (H) on the designated mark on the spray hose (E) G G Hot Cold E Designated Mark A E H Step 7: Flush faucet Remove spray head (A). Hold tip of spray hose (E). Turn faucet on for 1 minute to flush any debris.
Replacement Part List 1. A Index Button B Set Screw 2. Metal Handle 3. Cartridge Cover 6 4. Locking Nut 5. Cartridge 6. Spray Head 7 7. Set Screw 5 4 8. Quick Connect Assembly 3 2 9. Spray Hose 10. Weight 1 11 8 9 12 13 10 11. Cover & Putty Plate 12. Base 13. Hex Wrench 2.5mm 14.
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM 11 CAUSE ACTION Leaking from spray hose Quick Connect (8) may be installed incorrectly Remove Quick Connect (8) from spray hose (9) and reinstall. Make sure you hear a click when you install it on the spray hose (9) Water will not shut off completely Cartridge (5) may need to be adjusted or replaced Remove index button (1A).
Push Open Left Hot Water Care & Maintenance *To keep the product clean & shining, follow the steps below: 1. 2. 3. 4. Rinse with clean water & dry with a soft cloth Do not clean with soaps, acid, polish, abrasives, or harsh cleaners Do not use cloth with a coarse surface Unscrew the aerator and clean when necessary *This installation manual is subject to change without further notice. Download the Kraus Care & Maintenance Guide at: http://www.kraususa.
Codes/Standards Applicable: GREEN LEAD FREE IA P NSF/ANSI Standard 61 certified by IAPMO NSF/ANSI Standard 372 certified by IAPMO MO Meets ASME A112.18.1M/A112.18.1 R& T 1.75GPM 6.6L/min maximum TM Water Efficiency HELP LINE Our customer service hours are Monday – Friday, 9am – 8pm EST. Be sure to visit our website at www.kraususa.com If you are a homeowner please contact a Kraus Customer Service Representative at: Kraus USA, Inc.
