Specification

SPECIFICATION SHEET
REV. January 24, 2018Codes/Standards: Meets ASME A112.18.1/CSA B125.1, NSF/ANSI Standard 61 certied by IAPMO, NSF/ANSI Standard 372 certied
by IAPMO, CAL GREEN, CEC, DOE, ADA
1.800.775.0703 / [e-mail] Limited Lifetime Warranty: See website for details www.kraususa.com
Chrome / Stainless Steel Finishes
Oletto
™
/ KPF-2620
Single Lever Pull Down Kitchen Faucet
Type: Neoperl
Hose
Docking: Secure
Nozzles: Easy Clean Rubber Nozzles
Function: Spray & Stream
Name: Cache Perlator Honeycomb
Aerator: Neoperl/1.75GPM
Flow Rate: 1.75 gpm (6.6L/min) @ 60 psi
Sprayhead
Pull Down
Design: Full Body
Swivel: 360
Spout
Waterway: Brass
Sprayer: Plastic
Handle: Zinc
Body: Metal
Material
Escutcheon Plate, Weight, Hex Wrench
Accessories Included
Handle Clearance: 1 1/4”
Faucet Dimensions: 15 3/4” x 8 3/4” x 2 1/2”
Dimensions
Factory Installed
Included
Materials: Braided Nylon
Connections: 3/8”
Flexible
Type : Neoperl, 700mm
Waterlines
Type: Quick Dock
Holes: 1 - 3 Holes
Mounting
Style: Lever
Size: 35mm
Brand: Kerox
Cartridge
9/16-24 UNEF
3/8” Compression
Check Value
8.7”
221mm
2.4”
62mm
7.3”
186mm
8.2”
208mm
15.75”
400mm
10.25”
260mm
4.31”
109mm
10.5”
267mm
0.06”~1.2”
1mm~30mm
1.6”
40mm
24.44”
620mm
15
º
