Instruction Manual

6 TECHNICAL DATA
22
BATCHFLUX 5500 C
www.krohne.com 05/2014 - 4000827703 - HB BATCHFLUX 5500 R03 en
6.2 Technical data
INFORMATION!
• The following data is provided for general applications. If you require data that is more
relevant to your specific application, please contact us or your local sales office.
• Additional information (certificates, special tools, software,...) and complete product
documentation can be downloaded free of charge from the website (Download Center).
Measuring system
Measuring principle Faraday's law
Application range Electrically conductive fluids
Measured value
Measured valueMeasured value
Measured value
Primary measured value Flow velocity
Secondary measured value Volume flow
Design
Features Tube: Zirconium oxide
Electrodes: Fused-in cermet (DN2.5...15) / Platinum (DN25...40)
Standard wet calibration
Modular construction The measurement system consists of a flow sensor and a signal
converter. It is only available as compact version.
Compact version BATCHFLUX 5500 C
Nominal diameter DN2.5...40 / 0.1...1½"
Measurement range -12...+12 m/s / -39...+39 ft/s
User interface
User interfaceUser interface
User interface
Operating data Factory set to customer specification.
Human Machine Interface (HMI) Option: BATCHMon Plus software
Cable connections Standard; 1x M12, 5-pin connector
With status output; 1x M12, 8-pin connector
