ESM Series User Guide s ESM26 s ESM12 The future of sound. Made perfectly clear. At KV2 Audio our vision is to constantly develop technologies that eliminate distortion and loss of information providing a true dynamic representation of the source. Our aim is to create audio products that absorb you, place you within the performance and deliver a listening experience beyond expectation.
Contents ESM26 Overview Drawing Specifications 3 3 4 5 ESM12 Overview Drawing ESM12L Drawing ESM12R Specifications 6 6 7 8 9 Accessories 10 Warranty 11 Service 11
Overview ESM26 ESM26 Application: t High quality floor monitoring applications t Very low dimensions, SPL and high quality sound t Ideal for TV studios and theaters MODEL NUMBER: PRODUCT CODE: ESM26 KVV 987 263 Description: The ESM26 is a full-range low profile 2-way, passive 2x 6” monitoring solution. The ESM26 features a revolutionary passive delay line which dramatically reduces feedback and the same 1.75” NVPD compression driver as used in the EX series.
Drawing ESM26 Drawing MODEL NUMBER: ESM26 PRODUCT CODE: KVV 987 263 4
Specifications ESM26 ESM26 Frequency response (half space) System Acoustic Perfomance Max SPL Long-term Max SPL Peak -3dB Response Recommended Power Sensitivity Impedance Crossover Point 123dB 126dB 70Hz ÷ 16kHz 275W 98dB 8Ω 2.5kHz High Frequency Section Acoustic Design High Horn Coverage Horizontal / Vertical Throat Exit Diameter / Diaphragm Size Diaphragm Material Magnet Type Horn Loaded 100° x 100° 1" / 1.
Overview ESM12 ESM12L, ESM12R Application: t )JHI RVBMJUZ øPPS NPOJUPSJOH BQQMJDBUJPOT t 1PSUBCMF 1" 4ZTUFNT GPS "7 TQFFDI BOE NVMUJNFEJB QMBZCBDL t 1FSJQIFSBM TVQQPSU GPS PUIFS &9 &4% &4 4- PS 7)% QSPEVDUT t )JHI RVBMJUZ öYFE JOTUBMMBUJPOT XJUI PS XJUIPVU TVCXPPGFST t 4NBMM UP NFEJVN TJ[FE -JWF .VTJD BQQMJDBUJPOT .0%&- /6.#&3 130%6$5 $0%& ESM12L KVV 987 216 .0%&- /6.#&3 130%6$5 $0%& ESM12R KVV 987 218 Description: 5IF &4.
Drawing ESM12L Drawing MODEL NUMBER: PRODUCT CODE: ESM12L KVV 987 216 7
Drawing ESM12R Drawing 8 MODEL NUMBER: PRODUCT CODE: ESM12R KVV 987 218
Specifications ESM12 ESM12 Frequency response System Acoustic Perfomance Max SPL Long-term Max SPL Peak -3dB Response Recommended Power Sensitivity Impedance Crossover Point 127dB 130dB 55Hz - 22kHz 500W 98dB 4Ω 1.
Accessories ESM Series COVERS PART NAME: PART NAME: COVER ESM26 COVER ESM12L PART NUMBER: PART NUMBER: KVV 987 281 KVV 987 262 PART NAME: COVER ESM12R PART NUMBER: KVV 987 261 SPEAKER CABLES PART NAME: 1m - round flexible speaker cable, cross section 2 x 1.5mm PART NAME: PART NUMBER: PART NUMBER: SPEAKON NL4 KVV 987 250 KVV 987 240 ESD, Speakon NL4 wiring Accessories positive pin (1 +, 2 + parallel) PART NAME: 1m - round flexible speaker cable, cross section 4 x 2.
Warranty SERVICE: In the unlikely event that your ESM develops a problem, it must be returned to an authorised distributor, service centre or shipped directly to our factory. Because of the complexity of the design and the risk of electrical shock, all repairs must be attempted only by qualified technical personnel. If the unit needs to be shipped back to the factory, it must be sent in its original carton. If improperly packed, the unit may be damaged.
