Instruction Manual

OPERATOR INSTRUCTIONS
AMPLIFICATION AND CONTROL REQUIREMENTS
This Active driven speaker must only be used in conjunction
with a KV2 Audio VHD2000 amplier.
Please refer to the VHD2000 and VHD3200 manuals for
precise system set up and operating instructions.
KV2 Audio
Nádražní 936
Milevsko, 399 01
Czech Republic
Tel: [phone]
www.kv2audio.com
KVV120023-00-02-0
VHD2.0
ACTIVE DRIVEN SPEAKER
System Acoustic Perfomance
Max SPL Lon
g
-term
139dB (144dB two VHD 2.0’s)
Max SPL Peak
142dB (147dB two VHD 2.0’s)
-3dB Res
p
onse
100Hz ÷ 22kHz
-10dB Response
85Hz ÷ 30kHz
Full Ran
g
e mode -3dB Res
p
onse
60Hz ÷ 22kHz
Crossover Point
100Hz, 450Hz, 2.2kHz
High Frequency Section
Acoustic Desi
g
n
Horn Loaded
Hi
g
h Horn Covera
g
e Horizontal / Vertical
80° x 40° / 80° x 10° (2x VHD 2.0's)
Hi
g
h Frequenc
y
Amplier Requirement
200W (VHD2000 am
p
.)
Throat Exit Diameter / Diaphra
g
m Size
1.4” / 3.0”
Diaphra
g
m Material
Nitride Titanium
Ma
g
net T
y
pe
Neod
y
mium
Mid Range Section
Acoustic Desi
g
n
Horn Loaded
Mid Horn Covera
g
e Horizontal / Vertical
80° x 40° / 80° x 10° (2x VHD 2.0's)
Midran
g
e Amplier Requirement
600W (VHD2000 am
p
.)
Woofer Size / Voice Coil Diameter / Desi
g
n
2x 8" / 3.0" / Trans Coil
Diaphra
g
m Material
E
p
ox
y
Reinforced Cellulose
Ma
g
net T
y
pe
Neod
y
mium
Mid-Bass Section
Acoustic Desi
g
n
Horn Loaded
Mid-bass Am
p
lier Re
q
uirement
1200W (VHD2000 am
p
.)
Woofer Size / Voice Coil Diameter / Desi
g
n
2x 12" / 3" / Inside Outside
Dia
p
hra
g
m Material
E
p
ox
y
Reinforced Cellulose
Ma
g
net T
yp
e
Neod
y
mium
Speaker Input
Speaker Input
EP6
Cabinet
Cabinet Material
Baltic birch
Handles
6
Color
"Orange peeled" Matt Black
or an
y
RAL
Physical Dimensions
Hei
g
ht
933mm (36.72")
Width
700mm (27.55")
Depth
495mm (19.48")
Wei
g
ht
70k
g
(154.0lbs)
Amplification and control
Amplification and control
VHD2000
Product Number:
KVV 987 077 - VHD2.0 R (right)
KVV 987 078 - VHD2.0 L (left)
