TX5U Wireless Rain Gauge Instruction Manual
TABLE OF CONTENTS Topic Inventory of Contents Additional Equipment Detailed Setup Guide Battery Installation Mounting Maintenance and Care Specifications Warranty Information Page 2 2 3 3-4 4 4 5-6 INVENTORY OF CONTENTS 1. The remote rain sensor. 2. Instruction manual and warranty card. ADDITIONAL EQUIPMENT (not included) 1. 1 Philips screwdriver 2.
DETAILED SET-UP GUIDE FOR THE WIRELESS RAIN GAUGE I) Battery Installation Note: Batteries will fit tightly. To avoid start-up problems make sure that the batteries do not spring free. A) Remote Rainfall Sensor Battery compartment Battery cover 1. Remove the flat-head screw and battery cover located on the underside of the base. 2. Observing the correct polarity install two AA batteries. 3. Make sure the rubber weather seal is in place and replace the battery cover and screw. 4.
3. Place the base over a desired mounting surface. 4. With a pencil mark the mounting surface through the cylindrical holes. 5. Where marked start the screws. 6. Place the base over mounting surface. 7. Install screws through the cylindrical holes and into the started holes on the mounting surface. 8. Secure the screws, ensuring that no part of the base can lift off the mounting surface. 9. Remove the manufacturers tape from the teeter-totter on the base.
WARRANTY INFORMATION La Crosse Technology, Ltd provides a 1-year limited warranty on this product against manufacturing defects in materials and workmanship. This limited warranty begins on the original date of purchase, is valid only on products purchased and used in North America and only to the original purchaser of this product. To receive warranty service, the purchaser must contact La Crosse Technology, Ltd for problem determination and service procedures.
This handbook may contain mistakes and printing errors. The information in this handbook is regularly checked and corrections made in the next issue. We accept no liability for technical mistakes or printing errors, or their consequences. All trademarks and patents are acknowledged. FCC ID: OMO-01TX (transmitter) THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2.
