Troubleshooting
84
5
D
DD
D
Holding the grips of the toner car-
tridge, insert it into the printer
until it stops.
E
EE
E
Push down the toner cartridge to
settle it in appropriate position.
F
FF
F
Close the front cover.
Important
❒ If paper is fed from the Bypass
Tray, be sure to remove all the
paper from the Bypass Tray and
close it before opening the front
cover.
When "Remove Misfeed Paper
Exit Cover" Appears
R
CAUTION:
Important
❒ Forcefully removing misfed paper
may cause paper to tear and leave
scraps of paper in the printer. This
might cause a misfeed and damage
the printer.
A
AA
A
If you installed the 1-bin Shift
Sort Tray, slide the upper tray out
from it. If you installed the Mail-
box, slide the output tray into
lower slide out from it.
The following procedures are ex-
ample of Mailbox.
ZGDT120J
ZGDT140J
ZGDH130J
• When removing misfed paper,
do not touch the fusing section
because it becomes very hot.
• The fusing unit becomes very
hot. When installing the new fus-
ing unit, turn off the printer and
wait about an hour. After that, in-
stall the new fusing unit. Not
waiting for the unit to cool down
can result in a burn.
ZGDY370J
