14: Advanced Settings

EDS1100/2100 User Guide 135

XML Export Configuration

To export a system configuration record, perform the following steps.

1. Click XML on the Main Menu. Figure 14-5 shows the page that displays.

Figure 14-5 XML Export Configuration Web Page

2. Enter or modify the fields in Table 14-3:

Table 14-3 XML Export Configuration Fields

Field Description

Export to browser Select this option to export the XCR data in the selected fields to a web

browser.
