14: Advanced Settings

EDS1100/2100 User Guide 140

Figure 14-9 Import Configuration from Filesystem Web Page

6. Enter the fields shown in Table 14-5.

Table 14-5 Import Configuration from Filesystem Fields

Field Description

Filename Enter the name of the file on the EDS1100/2100 (local to its filesystem) that

contains XCR data.
