7: Network Settings

EDS1100/2100 User Guide 40

2. Click Network 1 > Link. Figure 7-4 shows the page that displays.

Figure 7-4 Network1 (eth0) Ethernet Link Web Page

3. Enter or modify the fields in Table 7-5.

4. Click Submit.

Table 7-5 Network 1 (eth0) Ethernet Link Fields

Field Description

Speed Select the Ethernet link speed. Auto is the default.

Duplex Select the Ethernet link duplex mode. Auto is the default.
