Data Sheet

U.I. Lapp
GmbH
DATA SHEET
JE-LiYCY...BD EB
DB0034220
valid from: 23.11.2012
Originator: PESA / PDC
approved: HAPF / PDC
Document: DB0034220DE page 1 of 1
All rights reserved acc. to DIN ISO 16016.
PD 0019/2.2_11.10EN
Application
JE
-
LiYCY...BD EB
is a connecting cable for industrial electronics. It can be used in measurement and control engineering
and also as pulse and data transmission cable.
With the blue outer sheath the cable is designed for the installation of intrinsically safe circuits in hazardous (explosive)
areas.
The cable meets the requirements of VDE 0165 part 1 where a special marking for cables of hazard type “i”
(intrinsically safe) is specified.
The cable is manufactured according to DIN VDE 0815. The requests for make-
fulfilled.
The cable is suited for limited flexing use and fixed installation in dry and wet rooms on and under plaster.
Design
Outer sheath
Colour of the sheath: sky blue (RAL 5015)
Electrical properties at 20°
Loop resistance
max. 78.4
Ω/km
Insulation resistance
> 100 M
Ω x km
Mutual capacitance
100 nF/km
Inductivity
0.65 mH/km
Capacitive coupling
200 pF/100 m
Peak
working voltage
225 V (not for power applications)
Test voltage
C/C: 500 V
C/S: 2000 V
Mechanical and thermal properties
Bending radius
Flexing: 15 x cable Ø
Fixed inallation: 6 x cable Ø
Temperature range
Flexing:
-
5
˚C up to +70˚C
Fixed installation: - 40˚C up to +70˚C
Flammability
flame retardant acc. to IEC 60332
-
1
-
2
EC directive
This cable is conform to the EC
-
Directive 2002/95/EC and 2011/65/EC
(RoHS, Restriction of the use of certain hazardous substances).
Design based on standard DIN VDE
0815, Table 5, Type JE
-
LiYCY...BD
Electrical properties based on standard DIN VDE 0815, Table 11, Type JE-LiYCY…BD
Tests at the cable based on DIN VDE 0815, Tabelle 21
