Data Sheet

DATA SHEET
DB0037000EN
ÖLFLEX
®
SERVO 9YSLCY-JB
with UL AWM approvals for USA & Canada
Valid from :
10.06.2010
Prepared by:
PD-KL – V. Huber 250309
Rev. V. Huber 070809; 100610
Document: DB0037000EN_3.doc Sheet 1 of 3
Application
ÖLFLEX
®
SERVO 9YSLCY-JB are flexible cables having special EMC- performance due double shielded, low
capacitance design. UL -AWM approvals for USA & Canada. Ideal for frequency converters for variable speed of 3
~ AC motors, small, medium and large sizes. Contrary to usage of PVC-insulated cables, PP -insulated cables
shows significant reduction of useless reactive power always needed for charging and discharging the cable
during operating of the frequency converter. Type 9YSLCY-JB BK has a special concentric conductor array
design, where the PE- functionality is to split into 3 individual conductors and its screen. Its highly symmetrical and
concentric design avoids from all cable-relevant parts of high frequency discharge currents, passing lubricating
film of motors bearings. This effect may damage motors bearing, especially if switching frequency of the frequency
converter is very high (up to 20 kHz) and / or long cable lengths are required. This balanced design also improves
EMC noise situation due reduction of the common mode coupling effects of the whole drive system.
Cables are suitable in dry, damp and wet rooms/ locations. 9YSLCY-JB BK version is UV-light protected for
outdoor use incl. direct burial. Its AWM approval does not cover an outdoor usage in USA and Canada. Good
resistance against acids, caustic solutions and certain oils at room temperature. Suitable for occasional, non
repeatable flexing, as well as for static use. Not suitable for continuously moving appliance under tensile load or if
during flexing, accompanied by guidance. Conform to Europeans LVD & ROHS directives.
Design
Conductor fine wire strand of bare copper, in acc. to IEC/EN/DIN 60228 / VDE 0295 Cl. 5
Insulation: Polypropylene (PP) Type 9Y, low capacitance
Cond.-Ident-Code: acc. HD 308 S2 / VDE 0293-308 with one common or to split gnye protectiv
conductor.
Twisting 4 -conductors or 3 + 3 -conductors, twisted together in one layer.
Screening: Aluminium -Mylar tape wrap, metal-side outwards, on top a tinned copper wire braid.
Sheath: 9YSLCY: PVC sheath transparent flame retardant & self-extinguishing.
9YSLCY BK: PVC sheath black, allows outdoor- and direct burial use, flame retardant &
self-extinguishing acc. IEC 60332.1-2, VW-1, FT1
Marking on the sheath:
P/N 003700 up to 0037014: Black imprint on transparent sheet:
Example: # 0037011
LAPPKABEL
ÖLFLEX
®
SERVO 9YSLCY-JB 4G120 IEC 0.6/1kV 80° ROHS CE
AWM Style 2570 1000V 80° VW-1 AWM II A/B 1000V 80° FT-1 E63634
P/N 0037015 up to 0037028: White imprint on black sheet:
Example: # 0037026
LAPPKABEL
ÖLFLEX
®
SERVO 9YSLCY-JB BK 3X120+3G16 IEC 0.6/1kV 90° ROHS CE
AWM Style 2570 1000V 80° VW-1 AWM II A/B 1000V 80° FT-1 E63634
Electrical properties at 20°C
Specific insulation resistance min. 20 GΩ x cm
Transfer impedance max. 250 Ω / km at 30MHz
Nominal voltage IEC U0/U: 600/1000V
UL/CSA: 1000V
Test voltage: core/core & core/braid 4000V
Further data: see page 2 and 3
