Data Sheet

DATA SHEET
0066202
UNITRONIC
LiYCY (TP) UL/CSA
gültig ab :
13.02.2008
ausgearbeitet von:
TE-K: Petra Samek
Dokument: DB0044602_3EN Blatt 1 von 1
Nr.: 0019/0894
Application
UNITRONIC LiYCY (TP) UL/CSA is a flexible cable with UL and CSA approval.
UNITRONIC LiYCY (TP) UL/CSA is for internal and external wiring of electronic components, equipments
and plants, especially for the export to North American markets or to countries in which cables approved by
UL/CSA are in extended use.
The cable is for flexible use and for static laying in dry and damp interiors intended, but not for use outside
and in power chains.
Design
Conductor multiple wire strands of tinned copper wires
UL Style 1061 AWG 26, 0,14 mm
2
(7 x 0,16)
AWG 24, 0,23 mm
2
(7 x 0,2)
UL Style 1007 AWG 22, 0,34 mm
2
(7 x 0,25)
AWG 20, 0,5 mm
2
(7 x 0,3)
AWG 19, 0,75 mm
2
(19 x 0,22)
AWG 18, 1,0 mm
2
(19 x0,254)
AWG 16, 1,5 mm
2
(19 x 0,32)
Insulation Semi-Rigid PVC AWG 26, bis AWG 24
UL Class 12 PVC AWG 22, bis AWG 16
Coding to DIN 47100
Stranding cores twisted to pairs, pairs twisted in layers, wrapping by plastic foil
Screening braid of tinned copper, coverage approx. 85%
Sheath PVC compound acc. to UL Class 43
Color chrome grey (RAL 7005)
Technical data
Specific insulation resistance >20
G x cm
Operating Voltage (not for power purposes) 300
V
Test voltage 1500
V
Flame propagation flame retardant to IEC 60 332-1-2, UL VW 1 and CSA FT 1
Minimum bending radius moved
15
x cable Ø
Temperature range static
-30 bis +80
°C
Design and electrical characteristics similar to Standard VDE 0812
Approbation UL Style 2464, CSA AWM I/II A,B 80°C, 300 V
RoHS directive
This cabel confirms to RoHS directive (2002/95/EG)
