User Guide

EPL-48-2L-LED-SFC
Materials
Copper Free Aluminum Housing
Heavy Gauge Aluminum Reectors
Tempered Borosilicate Lens
Mounting
Adjustable L-Shape Surface Mount Brackets
Dimensions
L-51.48” x W-11.87” x H-8.95”
Wiring Hub
1/2 inch threaded NPT
Voltage
Universal 120-277 Volts AC 50/60 Hz
120V-60Hz, 220V-50Hz, 240V-60Hz,
277V-60Hz
Weight
42.9 Lbs
Wattage
56 watts
Lumens
7,000 Lumens
Color Temp
5,600K, 4,500K, or 3,000K
Avg Lamp Life
50,000+ Hours
Ambient Temp
-40C to +65C
Temp Rating
T6 Rated
Specications / Technical Information
• U.L. Listed - United States & Canada
• Class 1, Division 1, Groups C and D
• Class 1, Division 2, Groups A, B, C & D
• Class 2, Divisions 1 & 2, Groups E, F, & G
• UL 844
• UL 1598A Wet Location
• cUL Listed for Canada
• UL listed for Paint Spray Booths
• Meets USCG Specs
• T6 Temperature Rating
• Wall/Ceiling/Flat Surface Bracket Mounting System
Adjustable Surface Mount Brackets
Each bracket is cinched to the bracket mounting peg on
each side of the light. e angle of the bracket is set by
tightening two cap screws on either side of the bracket. e
cap screws act as a set screw. e bracket itself is mounted
via a single bolt hole at the top the bracket. ere are two
brackets, one on each end of the light. Once the brackets
are mounted to a surface (ceiling, oor or wall), the light
xture can be removed from the brackets by loosening the
cap screws that hold the bracket to the mounting peg.
Explosion Proof Lighting
