QUICK USER MANUAL MMC-B18 SMART MEDIA PLAYER WITH SET TOP BOX 1
QUICK USER MANUAL MMC-B18 Index The Remote control The Player Outputs Connecting to TV Connection to Internet The Home Screen The Apps Centre Smart Apps Settings Operating Live TV Feature Overview FAQ Specifications 3 4 5 6 9 10 11 12 14 19 20 21 IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS - Read all instructions carefully before use. - Retain manuals for future reference. - Use this product only in the manner described. - Only use a water-dampened soft-cloth to clean the surface of this product.
QUICK USER MANUAL MMC-B18 THE REMOTE CONTROL 1 2 3 4 5 6 7 8 14 9 10 11 12 16 15 Note. Some subscription based Apps may require a WIRED mouse or keyboard for setup and operation.
QUICK USER MANUAL MMC-B18 THE PLAYER OUTPUTS SIDE PANEL USB port (1) REAR PANEL RJ45 Network Ethernet port USB port (2) Digital Audio Coaxial output Micro SD Card slot HDMI Output AV output (3.
QUICK USER MANUAL MMC-B18 CONNECTING TO TV GOOD – via RCA Cables Note: RCA A/V Cable not supplied BEST – via HDMI Cable Note: HDMI A/V Cable not supplied 5
QUICK USER MANUAL MMC-B18 CONNECTION TO INTERNET GOOD – Wi-Fi WIRELESS MODEM Note: See page 7 for Wi-Fi setup. BEST – Direct Connection (to a Modem/Router) Note: Network cables not supplied Note: An Ethernet cable internet connection is recommended for streaming HD and FHD video.
QUICK USER MANUAL MMC-B18 Cable connection to the internet using a Modem/Router - Connect the network cable to the Media Player and your Modem/Router. - In most cases your Modem/Router will automatically assign network settings to your media player and display the screen below. Then click OK.
QUICK USER MANUAL MMC-B18 Note: If the wireless network is not encrypted, you can connect to it directly. If the network is encrypted, select the Wi-Fi name to pop up the window for password, press OK on the remote control and call out the soft keypad on the screen, enter the password, select “Next” on the keypad or press the Return key on the remote control to hide the keypad, and then select “Connect” to connect to it. (Note: to hide the keypad on the TV box, press the Return key on the remote control.
QUICK USER MANUAL MMC-B18 APP OVERVIEW The Home screen Note: Quickflix, Netflix, Skype and other subscription based Apps may require a WIRED mouse or keyboard for setup and operation. Live TV play and view Live TV (Antenna connection required) YouTube Stream Youtube Videos Music Player Play Music through the device Media Center Connect to DLNA Server to play Media Photo Viewer View photos on the device Netflix Stream Movies and TV for a Monthly price.
QUICK USER MANUAL MMC-B18 The Apps Centre File Browser Browse your files Media Player Play Media through the device My APPs View app the installed apps + Add apps to the Apps Centre screen 10
QUICK USER MANUAL MMC-B18 Smart Apps Play Store Access the Google Play Store.
QUICK USER MANUAL MMC-B18 Settings Ethernet Check the Ethernet Settings and IP information HDMI Change the screen resolution Wi-Fi Setup a Wi-Fi connection Screen Scale Adjust the screen scale to fit on screen properly System Upgrade Upgrade the System either via Storage or OTA (Over the Air) Language Change Language Network Speed Check the current Network Speed AutoRun Allow apps to auto run Sound Output Change the sound output (Note: Select PCM for use with the DTV App) Device Info View the dev
QUICK USER MANUAL MMC-B18 SETTINGS – SELECTING THE HDMI RESOLUTION Before operating for the first time, please adjust the screen resolution to achieve the optimal display: (Enter the Settings MENU and select HDMI) Note: This option is for HDMI outputs only. When the selected resolution is not supported by TV-Set, the system will automatically return to a recommended resolution. As a shortcut you can use the “RES” button on the remote control.
QUICK USER MANUAL MMC-B18 OPERATING LIVE TV (APP) Select the Live TV from the Home Screen Note: Visit the LASER web site and click the VIDEO tab on the PRODUCT PAGE or click http://www.laserco.com.
QUICK USER MANUAL MMC-B18 You then have the option to select between 3 different scans. These are Auto Scan (Recommended), Manual Scan or NIT Scan (Not available on this model). Note: Ensure this is set to Australia Wait for the scan to be complete. Note: Please wait 5-10 minutes for a complete auto scan. When finished, press the return button to exit the setup menu and start watching TV.
QUICK USER MANUAL MMC-B18 Edit Channel Menu Which viewing TV, press the MENU button to access the setup menu.
QUICK USER MANUAL MMC-B18 PVR Menu Access PVR Configure – Configure and manage storage for PVR to be recorded. PVR Manager – preview, play and delete recordings.
QUICK USER MANUAL MMC-B18 Tools Menu Change the following: Subtitle Language Audio Language Blackout Policy Information Show Time System Setup Menu Edit and change the following: System Language, TV System, Local Time Setting, Recall List, Subtitle Switch, Factory data reset, Set Password, Parental rating age, TTX Region Note: When in the Live TV app MENU the default password for “Set the Password” or “PVR Manager” functions is 0000 18
QUICK USER MANUAL MMC-B18 FEATURE OVERVIEW Digital Surround Sound All sound formats from 2 channel stereo to 7.1 Dolby and DTS. Also Flac lossless HD audio is supported. Android OS Smarts Android opens a world of possibilities through the Google Play store. Games, video players, apps, utilities and lots more.
QUICK USER MANUAL MMC-B18 FAQ Some apps I downloaded are not working properly. Why? Some apps not working properly with the remote. Why? My remote control is not working. Why? Why is google play not responding? How do I “Force Stop” an app, like Google Play Store? How do I do a factory reset? They may have not installed correctly. Please uninstall the apps and reinstall them again. Some apps are not designed to be used with a remote. I Suggest using a mouse instead.
QUICK USER MANUAL MMC-B18 SPECIFICATIONS Interface Power Supply Dimensions Composite AV Out (Jack to RCA) HDMI USB x 3 LAN Micro SD Card 5V 2A 150 x 98 x 36mm Warranty Against Defects Laser Corporation Pty Ltd (“Laser”) warrants your new product to be free from defects in materials and workmanship for 12 months, from the date of purchase, provided that the product is used in accordance with accompanying recommendations or instructions where provided.
