PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage. Suitable Location Assembling near the area of the intended location is highly recommended.
ASSEMBLY AND CARE ADVICE FAILURE TO FOLLOW THE GUIDELINES BELOW MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. Turn clockwise to tighten and only tighten when step is completed or when instructed to do so. Position each part correctly and insert screws or bolts into their respective holes. Use the appropriate hand tools or power tools for assembly. Select steps, such as tightening screws and/or bolts, may require hand tools to avoid causing damage during assembly.
CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Note : Every cam lock bolt must have a cam lock connector in order to fasten the parts together. cam bolt cam lock screwdriver 1 2 Screw the cam bolt into panel. Insert the cam bolt into the bolt hole of joint panel. 3 4 Align the cam lock with its side opening (or arrow) pointing to cam bolt. Turn the cam lock clockwise gently until it will not turn any more.
NIGHT STAND C A B G F J PARTS A 1PC B 1PC C 1PC D 1PC E 1PC F 1PC G 1PC H 1PC I 1PC J 1PC K 1PC L 1PC M 1PC N 1PC ACCESSORIES HARDWARE 1 17PCS 2 17PCS 3 10PCS (8x30) 5 1SET (4PCS) 6 8PCS 0.5" 4 4PCS A1 1PC A2 1SET A3 1PC A4 1SET A5 1PC A6 3PCS 2.2" 7 4PCS 1.
Identifying Drawer Rails Each drawer requires a set of 4 rails. Please review the below instructions to help identify the different rails. Left and right determined from the viewpoint of opening the drawer. Right/Left Panel Rail: (C-shaped frame) Align the drawer rails horizontally, with the oval and round holes resting flat against a surface. Rotate as needed so the rollers are located on your right-hand side. If the roller is closer to the bottom corner, this is the RIGHT panel rail.
ASSEMBLY COMPLETED Please ensure the furniture rests on an even and flat surface. If the product wobbles or feels loose, double-check all bolts and/or screws are properly tightened and secured. Keep this handy! Please retain this instruction manual and any order-related information for future reference. Lift, don’t drag! To avoid damage to product please always LIFT the product when transporting of adjusting the placement.
