Lenovo M30-70 / M40-70 ©Lenovo China 2014 en-US Rev. AA00 User Guide Read the safety notices and important tips in the included manuals before using your computer.
Note • Before using the product, be sure to read Lenovo Safety and General Information Guide first. • Some instructions in this guide may assume that you are using Windows® 7 or Windows 8.1. If you are using other Windows operating system, some operations may be slightly different. If you are using other operating systems, some operations may not apply to you. • The features described in this guide are common to most models.
Contents Chapter 1. Getting to know your computer .......................................... 1 Top view .......................................................................................................................1 Left-side view ..............................................................................................................3 Right-side view............................................................................................................4 Front view .......................
Chapter 1. Getting to know your computer Top view --------------------------------------------------------------------------------------------------a b c d e f Attention: • Do NOT open the display panel beyond 130 degrees. When closing the display panel, be careful NOT to leave pens or any other objects in between the display panel and the keyboard. Otherwise, the display panel may be damaged.
Chapter 1. Getting to know your computer a Integrated camera Use the camera for video communication. b Wireless module antennas The built-in antennas ensure optimal reception of wireless radio. c Computer display The LCD display with LED backlight provides brilliant visual output. d Power button Press this button to turn on the computer. e Built-in microphone The built-in microphone (with noise reduction) can be used for video conferencing, voice narration, or simple audio recordings.
Chapter 1. Getting to know your computer Left-side view -------------------------------------------------------------------------------------- a a Novo button b c d e When the computer is off, press this button to start the Lenovo OneKey Recovery system or the BIOS setup utility, or to enter the boot menu. Note: For details, see “Chapter 5. Lenovo OneKey Recovery system” on page 29. b Fan louvers Dissipate internal heat.
Chapter 1. Getting to know your computer Right-side view ---------------------------------------------------------------------------------- a a Memory card slot b c d Insert memory cards (not supplied) here. Note: For details, see “Using memory cards (not supplied)” on page 13. b Combo audio jack Connects to headphones or headsets. The combo audio jack does not support conventional microphones. c USB 2.0 port Connects to USB devices. Note: For details, see “Connecting USB devices” on page 14.
Chapter 1. Getting to know your computer Front view ----------------------------------------------------------------------------------------------- a a System status indicators For details, see “System status indicators” on page 17.
Chapter 1. Getting to know your computer Bottom view -----------------------------------------------------------------------------------------a b c d e a Battery latch manual The manual battery latch is used to keep the battery pack secured in place. b Louvers Allow air to enter the computer for cooling. c Battery latch spring loaded The spring-loaded battery latch keeps the battery pack secured in place. d Battery pack For details, see “Using AC adapter and battery” on page 8.
Chapter 2. Learning the basics First use ------------------------------------------------------------------------------------------------------ Reading the manuals Read the supplied manuals before using your computer. Connecting to the power The supplied battery pack is not fully charged at purchase. To charge the battery and begin using your computer, insert the battery pack and connect the computer to an electrical outlet. The battery is automatically charged while the computer is running on AC power.
Chapter 2. Learning the basics Using AC adapter and battery --------------------------------------------------------- Checking battery status You can determine the percentage of battery power remaining by checking the battery icon in the notification area. Note: As each computer user has different habits and needs, it is difficult to predict how long a battery charge will last. There are two main factors: • The amount of energy stored in the battery when you commence work.
Chapter 2. Learning the basics Handling the battery If the rechargeable battery pack is replaced with an incorrect type, there may be danger of an explosion. The battery pack contains a small amount of harmful substances. To avoid possible injury and detriment to the environment, pay attention to the following points: • Replace only with a battery of the type recommended by Lenovo. • Keep the battery pack away from fire. • Do not expose the battery pack to water or rain.
Chapter 2. Learning the basics Using the touchpad ------------------------------------------------------------------------------- d a b c a Touchpad To move the cursor on the screen, slide your fingertip over the pad in the direction in which you want the cursor to move. b Left-click area The function corresponds to that of the left mouse button on a conventional mouse, which can be implemented by clicking this area.
Chapter 2. Learning the basics Hotkeys -------------------------------------------------------------------------------------------------------The hotkeys are located in the first row of the keyboard. By pressing the appropriate hotkey, you can change system settings instantly. The following describes the function of each hotkey. : Mute/Unmute. : Decrease sound volume. : Increase sound volume. Close active window or : program. Refresh desktop or Web : pages. Enable/Disable the : touchpad.
Chapter 2. Learning the basics Setting hotkey mode By default, the hotkey functions are accessible by pressing the appropriate hotkey. However, you can disable the hotkey mode in the BIOS setup utility. To disable the hotkey mode: 1 Shut down the computer. 2 Press the Novo button and then select BIOS Setup. 3 In the BIOS setup utility, open the Configuration menu, and change the setting of HotKey Mode from Enabled to Disabled. 4 Open the Exit menu, and select Exit Saving Changes.
Chapter 2. Learning the basics Connecting external devices -----------------------------------------------------------Your computer has a wide range of built-in features and connection capabilities. Using memory cards (not supplied) Your computer supports the following types of memory cards: • Secure Digital (SD) card • MultiMediaCard (MMC) Note: • Insert ONLY one card in the slot at a time. • This card reader does not support SDIO devices (e.g., SDIO Bluetooth, etc.).
Chapter 2. Learning the basics Connecting USB devices You can connect a USB device to your computer by inserting its USB plug (Type A) into the USB port on your computer. The first time you plug a USB device into a particular USB port on your computer, Windows automatically installs a driver for that device. After the driver is installed, you can disconnect and reconnect the device without performing any additional steps.
Chapter 2. Learning the basics Connecting Bluetooth enabled devices (on select models) If your computer has an integrated Bluetooth adapter card, it can connect to and transfer data wirelessly to other Bluetooth enabled devices, such as notebook computers, PDAs and cell phones. You can transfer data between these devices without cables and up to 10 meters range in open space. Note: The actual maximum range may vary due to interference and transmission barriers.
Chapter 2. Learning the basics Special keys and buttons ------------------------------------------------------------------- a Novo button a • When the computer is off, press this button to start the Lenovo OneKey Recovery system or the BIOS setup utility, or to enter the boot menu. Note: For details, see “Chapter 5. Lenovo OneKey Recovery system” on page 29.
Chapter 2. Learning the basics System status indicators -------------------------------------------------------------------These indicators inform you of the computer status.
Chapter 2. Learning the basics No. a b Symbol Indicator Power Battery Indicator status On (solid white) Blinking Off On (solid white) Solid amber Fast blinking amber Slow blinking amber Slow blinking white Off 18 Meaning The computer is powered on. The computer is in sleep mode. The computer is powered off. The battery has more than 20% charge. The battery has between 5% and 20% charge. The battery has less than 5% charge. The battery is being charged.
Chapter 3. Starting to use Windows Configuring the operating system for the first time -------You need to configure the operating system when it is first used. The configuration process may include the procedures below: • Accepting the end user license agreement • Configuring the Internet connection • Registering the operating system • Creating a user account Operating system interfaces ---------------------------------------------------------This guide only takes Windows 8.
Chapter 3. Starting to use Windows Charms and the charms bar Charms are navigation buttons that let you access basic tasks quickly. Charms include: Search, Share, Start, Devices, and Settings. The charms bar is the menu that contains the charms. To display the charms bar, do one of the following: • Move the cursor to the upper-right or lower-right corner until the charms bar is displayed. • Press the Windows key + C.
Chapter 3. Starting to use Windows Share charm The Share charm lets you send links, photos, and more to your friends and social networks without leaving the app you are in. Start charm The Start charm is a fast way to go to the Start screen. Devices charm The Devices charm allows you to connect or send files to connected external devices, including the devices to play, print, and project.
Chapter 3. Starting to use Windows Power-saving modes -------------------------------------------------------------------------When you have finished working with your computer, you can put it to shut it down, sleep, or hibernate. Shutting down the computer If you are not going to use your computer for a long time, shut it down. To shut down the computer, do the following: • Windows 7: Click Start → Shut down. • Windows 8.1: 1 Open the charms bar, then select Settings 2 Select Power 22 → Shut down.
Chapter 3. Starting to use Windows Putting your computer to sleep If you will be away from your computer for only a short time, put the computer to sleep. When the computer is in sleep mode, you can quickly wake it to resume use, bypassing the startup process. To put the computer to sleep, do one of the following: • Close the display lid. • Press the power button. • Do the proper operations in the operating system. Windows 7: Click Start → Sleep. Windows 8.
Chapter 3. Starting to use Windows Help and support --------------------------------------------------------------------------------If you have questions about using the Windows operating system, refer to Windows Help and Support. To access Windows Help and Support, do one of the following: • Windows 7: Click Start → Help and Support. • Windows 8.1: • Open the charms bar and select Settings; select Help on the Settings menu. • Press Windows key + Fn + F1.
Chapter 4. Connecting to the Internet As a global network, the Internet connects computers worldwide, providing services such as e-mailing, information searching, electronic commerce, Web browsing and entertainment. You can connect the computer to the Internet in the following way: Wired connection: use physical wiring to connect. Wireless network technology: connect without wiring.
Chapter 4. Connecting to the Internet To insert a networking cable, do the following: 1 Hold one connector of the networking cable to press the RJ-45 cover down gently a . 2 Insert the connector into the RJ-45 port b . a a b Software configuration Consult your Internet Service Provider (ISP) for details on how to configure your computer.
Chapter 4. Connecting to the Internet Wireless connection---------------------------------------------------------------------------Wireless connections provide mobile access to the Internet, allowing you to stay online anywhere the wireless signal covers. Divided by the signal scales, wireless connection to the Internet can be built based on the following standards. Wi-Fi Wi-Fi networks cover a small physical area, like a home, office, or small group of buildings.
Chapter 4. Connecting to the Internet Connecting to wireless LAN Enabling wireless connection To enable wireless functions, do one of the following: • Press to disable airplane mode. • Open the charms and select Settings → to open the Network configuration page. Then toggle the airplane mode switch to off. Connecting to a wireless network To connect to a wireless network, do the following: 1 Press F7 to turn on the wireless feature. 2 View the available wireless networks.
Chapter 5. Lenovo OneKey Recovery system The Lenovo OneKey Recovery system is software designed to back up and restore your computer. You can use it to restore the system partition to its original status in case of a system failure. You can also create user backups for easy restoration as required. Note: • If your computer is preinstalled with a GNU/Linux operating system, OneKey Recovery system is not available.
Chapter 5. Lenovo OneKey Recovery system If Windows cannot be started, then follow the steps below to start the Lenovo OneKey Recovery system: 1 Shut down the computer. 2 Press the Novo button. From the Novo button menu, select the Lenovo OneKey Recovery system and press Enter.
Chapter 6. Troubleshooting Frequently asked questions ------------------------------------------------------------This section lists frequently asked questions by category. Finding information What safety precautions should I follow when using my computer? The Lenovo Safety and General Information Guide which came with your computer contains safety precautions for using your computer. Read and follow all the precautions when using your computer.
Chapter 6. Troubleshooting Lenovo OneKey Recovery system Where are the recovery discs? Your computer did not come with recovery discs. Use Lenovo OneKey Recovery system if you need to restore system to the factory status. What can I do if the backup process fails? If you can start backup but it fails during the backup process, try the following steps: 1 Close all open programs, then restart the backup process. 2 Check if the destination media is damaged. Select another path and then try again.
Chapter 6. Troubleshooting When do I need to change the boot mode? The default boot mode for your computer is the UEFI mode. If you need to install legacy Windows operating system (operating system before Windows 8) on your computer, you must change the boot mode to Legacy support. The legacy Windows operating system cannot be installed if you don't change the boot mode. Getting help How can I contact the customer support center? See “Chapter 3.
Chapter 6. Troubleshooting Troubleshooting -------------------------------------------------------------------------------------Display problems 34 When I turn on the computer, nothing appears on the screen. • If the screen is blank, make sure that: - The AC adapter is connected to the computer and the power cord is plugged into a working electrical outlet. - The computer power is on. (Press the power button again for confirmation.
Chapter 6. Troubleshooting BIOS password problems I forgot my password. • If you forget your user password, you must ask the system administrator to reset your user password. • If you forget your HDD password, a Lenovo authorized servicer cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized servicer or a marketing representative to have the hard disk drive replaced. Proof of purchase is required, and a fee will be charged for parts and service.
Chapter 6. Troubleshooting The computer does not return from sleep mode and the computer does not work. • If your computer is in sleep mode, connect the AC adapter to the computer, then press any key or the power button. • If the system still does not return from sleep mode, your system has stopped responding, and you cannot turn off the computer; reset the computer. Unsaved data may be lost. To reset the computer, press and hold the power button for 4 seconds or more.
Chapter 6. Troubleshooting Sound problems No sound can be heard from the speaker even when the volume is turned up. • Make sure that: - The Mute function is off. - The combo audio jack is not used. - The speaker is selected as the playback device. Battery problems Your computer shuts down before the battery status indicator shows empty. -orYour computer operates after the battery status indicator shows empty. • Discharge and recharge the battery.
Chapter 6. Troubleshooting Other problems 38 Your computer does not respond. • To turn off your computer, press and hold the power button for 4 seconds or more. If the computer still does not respond, remove the AC adapter. • Your computer might lock when it enters sleep mode during a communication operation. Disable the sleep timer when you are working on the network. The computer does not start from a device you want. • See the Boot menu of the BIOS setup utility.
Appendix. CRU (Customer Replaceable Units) instructions Note: Make sure the battery has been removed before replacing any devices. Replacing the battery ------------------------------------------------------------------------Note: Use only the battery provided by Lenovo. Any other battery could ignite or explode. To replace the battery, do the following: 1 Turn off the computer. Disconnect the AC power adapter and all cables from the computer. 2 Close the computer display, and turn the computer over.
Appendix. CRU (Customer Replaceable Units) instructions The following table provides a list of CRUs (Customer Replaceable Units) for your computer, and informs you of where to find replacement instructions.
Trademarks The following terms are trademarks or registered trademarks of Lenovo in the United States, other countries, or both. Lenovo OneKey Microsoft and Windows are trademarks of Microsoft Corporation in the United States, other countries, or both. Other company, products, or service names may be trademarks or service marks of others.
