2.Locatethebattery.See"Locatingpartsonthesystemboard"onpage95.

3.Removetheoldbattery.

4.Installthenewbattery.

5.Replacethecomputercover,andconnectthecables

Note:Whenthecomputeristurnedonforthersttimeafterbatteryreplacement,anerrormessage

mightbedisplayed.Thisisnormalafterreplacingthebattery.

6.Turnonthecomputerandallattacheddevices.

7.UsetheSetupUtilityprogramtosetthedateandtimeandanypasswords.See"UsingtheSetup

Utility"intheUserGuide

Replacingthepowersupply

Attention

Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.

Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabelattached.

Therearenoserviceablepartsinsidethesecomponents.

Attention

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe"Importantsafetyinformation"

intheThinkCentreSafetyandWarrantyGuidethatcamewithyourcomputer.ToobtainacopyoftheThinkCentre

SafetyandWarrantyGuide,goto:http://www.lenovo.com/support

Thissectionprovidesinformationonhowtoremoveandreplacethepowersupply.

Toremoveorreplacethepowersupply:

1.Removethecover.See"Removingthecover"onpage94.

2.Removethedrivebayassembly.See"Accessingsystemboardcomponentsanddrives"onpage96.

3.Disconnectallpowersupplycablesfromthesystemboard.See"Locatingpartsonthesystemboard"

onpage95

Chapter9ReplacingFRUs(Types7057,7062,7092,9342,9344,9354,9426,9486,9624,9707,9787,9804,9945)99
