Dimensions

Width:175mm(6.9in.)

Height:402mm(15.8in.)

Depth:440mm(17.3in.)

Weight

Maximumcongurationasshipped:11kg(24lbs)

Forallmachinetypes

Environment

•Airtemperature:

Operating:10°to35°C(50°to95°F)

Non-operating:-40°to60°C(-40°to140°F)

•Humidity:

Operating:10%to80%(10%perhour,noncondensing)

Non-operating:10%to90%(10%perhour)

•Maximumaltitude:

Operating:-50to10,000ft(-15.2to3048m)

Non-operating:-50to35,000ft(-15.2to10.668)

Electricalinput

•Inputvoltage:

–Lowrange:

Minimum:100Vac

Maximum:127Vac

Inputfrequencyrange:50/60Hz

Voltageswitchsetting:115Vac

–Highrange:

Minimum:200Vac

Maximum:240Vac

Inputfrequencyrange:50/60Hz

Voltageswitchsetting:230Vac

30ThinkCentreHardwareMaintenanceManual
