Chapter5.Diagnostics

Diagnosticprogramsareusedtotesthardwarecomponentsofyourcomputerandreport

operating-system-controlledsettingsthatcancausehardwarefailures.Therearetwodiagnosticprograms

preinstalledonyourcomputer:

•LenovoSystemToolbox(usedtodiagnoseproblemswhilerunningtheWindowsoperatingsystem)

•PC-DoctorforWindowsPE(usedwhenyourWindowsoperatingsystemdoesnotstart)

Notes:

1.YoucanalsodownloadthelatestversionoftheLenovoSystemToolboxandPC-DoctorforDOS

diagnosticprogramsfrom:http://www.lenovo.com/support

2.IfyouareunabletoisolateandrepairtheproblemyourselfafteryourunLenovoSystemToolboxand

PC-DoctorforWindowsPE,saveandprinttheloglescreatedbybothdiagnosticprograms.Youwill

needthelogleswhenyouspeaktoaLenovotechnicalsupportrepresentative.(Theloglecreatedby

LenovoSystemToolboxisautomaticallysavedinC:\PCDR\DETAILED.txt.)

LenovoSystemToolbox

LenovoSystemToolboxisadiagnosticprogramthatworksthroughtheWindowsoperatingsystemand

enablesyoutoviewsymptomsandsolutionsforcomputerproblems,accesstheLenovotroubleshooting

center,updatesystemdrivers,andreviewsysteminformation.

TorunLenovoSystemToolbox,clickStart®AllPrograms®LenovoSystemToolbox®LenovoSystem

Toolbox.Followtheinstructionsonthescreen.Foradditionalinformationaboutrunningthediagnostic

program,refertotheLenovoSystemToolboxhelpsystem.

IfyoustillsuspectaproblemafterLenovoSystemToolboxrunssuccessfully,runPC-DoctorforWindows

PEtohelpyoudiagnosethecomputerproblem.

LenovoSystemToolboxalsohasproblemdeterminationaidsthatdeterminesoftwareandusageproblems.

PC-DoctorforWindowsPE

ThePC-DoctorforWindowsPEdiagnosticprogramispartoftheRescueandRecovery®workspaceon

eachLenovocomputer.UsePC-DoctorforWindowsPE,ifyouareunabletostarttheWindowsoperating

systemorifPC-DoctorforWindowshasnotbeensuccessfulinisolatingapossibleproblem.

RunningdiagnosticsfromtheRescueandRecoveryworkspace

YoucanrunthePC-DoctorforWindowsPEdiagnosticprogramfromtheRescueandRecoveryworkspace.

TorundiagnosticsfromtheRescueandRecoveryworkspace,usethefollowingprocedure:

1.Shutdowntheoperatingsystemandturnoffthecomputer.

2.RepeatedlypressandreleasetheF11keyasyouturnonthecomputer.

3.Whenyouhearbeepsorseealogoscreen,stoppressingtheF11key.TheRescueandRecovery

workspaceopens.

4.FromtheRescueandRecoveryworkspace,selectDiagnosehardware.

5.Thediagnosticprogramopensautomatically.Selectthediagnostictestyouwanttorun.PresstheF1

keyforadditionalhelp.
