3.InserttheCDintotheopticaldriveortherstdiagnosticdisketteintothediskettedrive.

4.Restartthecomputer.

Note:Ifthediagnosticprogramdoesnotstart,youmightnothaveyouropticaldriveordiskettedriveset

asastartabledevice.See"Selectingastartupdevice"onpage41forinstructionsonhowtochange

thestartupdevice.

5.Whenthediagnosticsprogramopens,followtheinstructionsonthescreen.

Note:Ifyouarerunningdiagnosticsfromadiskette,whenprompted,removetherstdisketteand

inserttheseconddiskette.

6.Whentheprogramnishes,besuretoremovetheCDordiskettefromthedrive.

7.Selectthediagnostictestyouwanttorun.PresstheF1keyforadditionalhelp.

Navigatingthroughthediagnosticsprograms

Usethecursormovementkeystonavigatewithinthemenus.

•TheEnterkeyisusedtoselectamenuitem.

•TheEsckeyisusedtobackuptothepreviousmenu.

•ForonlinehelpselectF1.

Runningtests

Therearefourwaystorunthediagnostictests.

•Usingthecursormovementkeys,highlightRunNormalTestorRunQuickTestfromtheDiagnostics

menuandthenpressEnter.Thisautomaticallyrunsapre-denedgroupoftestsfromeachtestcategory.

RunNormalTestrunsamoreextensivesetofteststhandoesRunQuickTestandtakeslongerto

complete.

•PressF5toautomaticallyrunallselectedtestsinallcategories.

•Fromwithinatestcategory,pressCtrl-Entertoautomaticallyrunonlytheselectedtestsinthatcategory.

•Usingthecursormovementkeys,highlightasingletestwithinatestcategory,andthenpressEnter.

Thisrunsonlythattest.

PressEscatanytimetostopthetestingprocess.

Testresults(N/A,PASSED,FAILED,ABORTED)aredisplayedintheeldbesidethetestdescriptionandin

thetestlog.See"Viewingthetestlog"onpage36.

Toselectoneormoretests,usethefollowingprocedure.

1.Openthecorrespondingtestcategory.

2.Usingthecursormovementkeys,highlightthedesiredtest.

3.Pressthespacebar.

Aselectedtestismarkedby>>.Pressingthespacebaragainde-selectsatestandremovesthe>>.

4.Repeatsteps2and3abovetoselectalldesiredtests.

Testresults

Diagnosticstestresultsproducethefollowingerrorcodeformat:

FunctionCode

FailureTypeDeviceIDDate

ChkDigits

Text

Chapter5Diagnostics35
