1.Removethecomputercover.See"Removingthecover"onpage68.

2.Removethefrontbezelbyreleasingthethreeplastictabsinsidethechassisandpivotingthebezel

outward.Carefullysetthebezeltothesidewithoutdisconnectingthepowerswitch/LEDassemblycable.

3.Toreinstallthebezel,aligntheplastictabsontherightsideofthebezelwiththecorrespondingholesin

thechassis,thenpivotitinwarduntilitsnapsintopositionontheleftside.

Replacingthepowersupply

Attention

Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.

Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabelattached.

Therearenoservicablepartsinsidethesecomponents.

Attention

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe"Importantsafetyinformation"

intheThinkCentreSafetyandWarrantyGuidethatcamewithyourcomputer.ToobtainacopyoftheThinkCentre

SafetyandWarrantyGuide,goto:http://www.lenovo.com/support

72ThinkCentreHardwareMaintenanceManual
