Replacingthediskettedrive

Attention

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe"Importantsafetyinformation"

intheThinkCentreSafetyandWarrantyGuidethatcamewithyourcomputer.ToobtainacopyoftheThinkCentre

SafetyandWarrantyGuide,goto:http://www.lenovo.com/support

Thisprocedureprovidesinformationonhowtoremoveandreplacethediskettedrive.

Toremoveorreplacethediskettedrive,dothefollowing:

1.Removethecomputercover.See"Removingthecover"onpage68.

2.Removethefrontbezel.See"Removingandreplacingthefrontbezel"onpage71.

3.Disconnectthesignalandpowercablesfromtherearofthediskettedrive.

4.Pressthereleasebuttonandslidethediskettedriveoutthefrontofthecomputer.

5.Removetheretainerbracketfromthefailingdiskettedriveandinstallitonthenewdiskettedrive.

6.Slidethenewdiskettedriveintothedrivebayuntilitsnapsintoposition.

7.Connectthesignalandpowercablestothedrive.

8.Goto"CompletingtheFRUreplacement"onpage91.

Chapter8ReplacingFRUs(Types7061,7090,9353,9421,9485,9623,9625,9705,9786,9795,9935,9946,9953)85
