3656PowerCordsFRU#CRU

Powercord-US(modelsAAUAAFAASAALAAYAAAAAT)

41R31841

Powercord-US(modelsAAUAAFAASAALAAYAAAAAT)

41R31851

Powercord-China(modelsAAC)

41R32561

Powercord-China(modelsAAC)

41R32571

Powercord-JapaneseandJapaneseEnglish(modelsAAEAAJ)

41R32481

Powercord-JapaneseandJapaneseEnglish(modelsAAEAAJ)

41R32491

Powercord-Brazil(Portigese)(models)

41R32701

Powercord-Brazil(Portigese)(models)

41R32711

Powercord-LAHighVolt(APU)(models)

41R31761

Powercord-LAHighVolt(APU)(models)

41R31771

Powercord-ANZ(models)

41R31961

Powercord-ANZ(models)

41R31971

Powercord-Korea(models)

41R32601

Powercord-Korea(models)

41R32611

Powercord-UK,Ireland,Singapore,Malaysia,Brunei,Hongkong(modelsAABAAH)

41R32241

Powercord-UK,Ireland,Singapore,Malaysia,Brunei,Hongkong(modelsAABAAH)

41R32251

Powercord-Taiwan(modelsAAV)

41R32781

Powercord-Taiwan(modelsAAV)

41R32791

Powercord-Italy(models)

41R32321

Powercord-Italy(models)

41R32331

Powercord-Indonesia,Laos,Cambodia,Vietnam,Austria,Belgium,Croatia,Czechoslovakia,

Finland,France,Germany,Hungary,Netherlands,Norway,Poland,Portugal,Romania,Spain,

Sweden(modelsAAUAAFAASAALAAYAAAAAT)

41R32081

Powercord-Indonesia,Laos,Cambodia,Vietnam,Austria,Belgium,Croatia,Czechoslovakia,

Finland,France,Germany,Hungary,Netherlands,Norway,Poland,Portugal,Romania,Spain,

Sweden(modelsAAUAAFAASAALAAYAAAAAT)

41R32091

Powercord-Denmark(modelsAAG)

41R32121

Powercord-Denmark(modelsAAG)

41R32131

Powercord-Switzerland(modelsAAG)

41R32281

Powercord-Switzerland(modelsAAG)

41R32291

Powercord-Israel(modelsAAG)

41R32361

Powercord-Israel(modelsAAG)

41R32371

Powercord-SouthAfrica(modelsAAGAAMAAA)

41R32201

Powercord-SouthAfrica(modelsAAGAAMAAA)

41R32211

Powercord-India(modelsAAQ)

41R33411

Powercord-India(modelsAAQ)

41R31751

Powercord-Thailand(models)

43N90291

Powercord-Thailand(models)

43N90301

Powercord-Brazil(models)

43N90441

Chapter10FRUlists123
