7092Keyboards(LenovoPreferredProPS/2FullSize)FRU#
CRU
Tier
PS/2Full--Italy(models)
41A50581
PS/2Full--Japanese(models)
41A50591
PS/2Full--Korean(models)
41A50601
PS/2Full--LASpanish(models)
41A50611
PS/2Full--Norwegian(models)
41A50621
PS/2Full--Polish(models)
41A50631
PS/2Full--Portugese(models)
41A50641
PS/2Full--Romanian(models)
41A50651
PS/2Full--Russian/Cyrillic(models)
41A50661
PS/2Full--Serbian/Cyrillic(models)
41A50671
PS/2Full--Slovak(models)
41A50681
PS/2Full--Spanish(models)
41A50691
PS/2Full--Swedish/Finnish(models)
41A50701
PS/2Full--SwissF/G(models)
41A50711
PS/2Full--Thailand(models)
41A50721
PS/2Full--Turkish(models)
41A50731
PS/2Full--Turkish(models)
41A50741
PS/2Full--UKEnglish(models)
41A50751
PS/2Full--USEuro(models)
41A50761
PS/2Full--Slovenian(models)
41A50771
7092miceFRU#CRU
OpticalWheelMouseOPT(400DPI,USB)(models99G)
41U30131
OpticalWheelMouseOPT(400DPI,USB)(models99G)
41U30301
PS/2ThreeButtonballmousescrollpoint(41R0017)(models)
41R00181
7092AdaptersandmiscellaneousFRUsFRU#CRU
InternalUSBMemoryCardReaderoppybay(models)
41R33782
Internal20in1USBMemoryCardReader(modelsCTO)
45R81391
NVIDIAGeForce9300GE256MFullHeight(DVI+VGA)(TOWER)(models)
53Y58232
ATIHD2600XT512MB128BITATX(models)43C0261
2
IEEE1394FirewireAdapterSFF(models)
41D27812
IEEE1394FirewireAdapterATX(models)
41D27812
SoftModemV.90/V.44SFF(ROCKYS)(modelsCTO)
46R42202
SoftModemV.90/V.44ATX(models)
29R97292
ATIHD2400PRO128MB64BITDMS59LP(models)43C0259
2
ATIHD2400PRO128MB64BITDMS59ATX(models)43C0259
2
ATIHD2400XT256MB64BITDMS59LPSecondary(models)
64Y39972
